The Anatomy of Kubernetes Persistent Storage: PV, PVC and the Parts That Bite

Most explanations of Kubernetes storage stop at the analogy. A PersistentVolumeClaim is a request, a PersistentVolume is the thing you get, and a StorageClass describes how to make one. That is correct, it takes about five minutes to learn, and it will not help you at three in the morning when a claim has been sitting in Terminating for twenty minutes and nobody can explain why.

The parts that actually cost people data are in the lifecycle: who deletes what, when, and what survives. A default you never chose decides whether removing a PVC also destroys the disk behind it. An access mode that reads like a lock is not enforced at all. A volume you carefully set to Retain will sit in Released refusing every new claim until you edit a field nobody told you about.

This post is the anatomy: the five objects, how they bind, and the seven behaviours that surprise people. Every rule here is checked against the upstream Kubernetes documentation, and the exact strings and version numbers are quoted so you can verify them rather than take my word for it.

TLDR

• ReadWriteOnce means one node, not one pod. Several pods on the same node can all mount an RWO volume read-write. ReadWriteOncePod is the one that means what people assume RWO means.
• Access modes are not enforced. Upstream says plainly that RWO, ROX and RWX "don't set any constraints on the volume". Only ReadWriteOncePod is a real constraint.
• reclaimPolicy defaults to Delete. For dynamically provisioned volumes, deleting the PVC deletes the disk and the data on it.
• A PVC stuck in Terminating is usually working correctly. The kubernetes.io/pvc-protection finalizer holds it until no pod is using it.
• Retain does not mean reusable. The PV goes to Released and will not bind again while its claimRef is set.
• Volume expansion is one way. You can grow a PVC, never shrink it, and editing the PV's capacity by hand stops the resize from happening at all.
• StatefulSet PVCs outlive the StatefulSet by default. persistentVolumeClaimRetentionPolicy changes that, and it went GA in Kubernetes v1.32.

Prerequisites

• A Kubernetes cluster you can create and delete objects in, ideally not a production one
• kubectl configured against it
• Familiarity with pods and either Deployments or StatefulSets
• A CSI driver installed if you want to try dynamic provisioning, which is the default on every managed cloud offering

The five objects

Kubernetes storage is often described as two objects. It is really five, and the two that get left out are the ones that decide what happens to your data.

The split worth internalising is namespaced versus cluster-wide. A PVC lives in a namespace, belongs to a team, and is deleted when that namespace is deleted. A PV and a StorageClass are cluster objects owned by whoever runs the cluster. Deleting a namespace therefore deletes claims, and what that does to the underlying disks depends entirely on a policy set by someone else.

The fifth object, which you rarely write by hand, is the CSI driver. It is the thing that actually calls the cloud API to create a disk and attaches it to a node. When storage misbehaves in ways the objects above cannot explain, the driver's controller and node pods are where the answer is.

PV vs PVC: supply and demand

The cleanest way to hold the distinction is that a PVC is demand and a PV is supply.

A claim says what the workload needs, in the workload's own namespace, without knowing anything about the infrastructure:

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: postgres-data
  namespace: databases
spec:
  accessModes:
    - ReadWriteOnce
  storageClassName: fast-ssd
  resources:
    requests:
      storage: 100Gi

A PersistentVolume is the supply side: a real piece of storage, described in cluster terms.

There are two ways supply appears, and knowing which one you are using tells you who is responsible when things go wrong.

Dynamic provisioning is what every managed cluster gives you by default. It is also why so many people have never looked at a PV object: one is quietly created and destroyed on their behalf, carrying policies they did not set.

Binding is one-to-one, and it is sticky

Once a claim finds a volume, the two are wired together permanently. Upstream is unambiguous:

Once bound, PersistentVolumeClaim binds are exclusive, regardless of how they were bound. A PVC to PV binding is a one-to-one mapping, using a ClaimRef which is a bi-directional binding between the PersistentVolume and the PersistentVolumeClaim.

Two consequences follow, and both catch people out.

You cannot point two claims at one volume to share it. If you need several pods writing to the same storage, that is an access mode and a driver question, not a binding question. One PV serves exactly one PVC.

The binding is recorded on both objects. The PV gets a claimRef naming the claim. This is the field that makes a Retained volume refuse to be reused, which we come to below.

If you want a specific claim to land on a specific volume, you pre-bind by naming the volume in the claim. Note the empty storageClassName, which upstream flags explicitly:

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: foo-pvc
  namespace: foo
spec:
  storageClassName: "" # Empty string must be explicitly set otherwise default StorageClass will be set
  volumeName: foo-pv

Leave storageClassName off entirely and the default StorageClass is applied, dynamic provisioning kicks in, and you get a brand new empty disk instead of the volume you were trying to attach to. That is a genuinely nasty failure, because it looks like success: the pod starts, the mount is there, and the data is simply gone.

Access modes: the part almost everyone gets wrong

This is the single biggest misconception in Kubernetes storage, and it is worth stating bluntly.

ReadWriteOnce does not mean one pod. Here is the upstream definition, verbatim:

ReadWriteOnce: the volume can be mounted as read-write by a single node. ReadWriteOnce access mode still can allow multiple pods to access (read from or write to) that volume when the pods are running on the same node. For single pod access, please see ReadWriteOncePod.

So an RWO volume happily serves three pods at once, as long as the scheduler put them on the same node. Teams discover this when a rolling update briefly runs old and new pods together, both writing, and a database that assumed exclusive access finds its files corrupted. The behaviour is not a bug and it is not a driver quirk. It is the documented meaning of the mode.

The four modes and their kubectl abbreviations:

Mode	Short	What it actually means
ReadWriteOnce	RWO	Read-write by a single node, any number of pods on it
ReadOnlyMany	ROX	Read-only by many nodes
ReadWriteMany	RWX	Read-write by many nodes, needs a driver that supports it
ReadWriteOncePod	RWOP	Read-write by exactly one pod, cluster-wide

Now the second half, which is less known and more alarming. Access modes on a PV are, with one exception, not enforced by anything:

Even if the access modes are specified as ReadWriteOnce, ReadOnlyMany, or ReadWriteMany, they don't set any constraints on the volume. For example, even if a PersistentVolume is created as ReadOnlyMany, it is no guarantee that it will be read-only. If the access modes are specified as ReadWriteOncePod, the volume is constrained and can be mounted on only a single Pod.

Read that again. ReadOnlyMany does not make a volume read-only. The access mode is matching metadata used when pairing claims with volumes, not a lock applied to the storage. If you want a hard guarantee that exactly one pod can write, ReadWriteOncePod is the only mode that provides one, it is CSI-only, and it graduated to stable in Kubernetes v1.29.

The reclaim policy decides whether you keep your data

Every PV carries a persistentVolumeReclaimPolicy that says what happens when its claim goes away.

Delete removes the PV object and the storage asset in the external infrastructure. The disk is gone. This is the important part:

Volumes that were dynamically provisioned inherit the reclaim policy of their StorageClass, which defaults to Delete.

And on the StorageClass side:

If no reclaimPolicy is specified when a StorageClass object is created, it will default to Delete.

Put those together. On a default managed cluster, with a StorageClass nobody edited, kubectl delete pvc destroys the underlying disk. Delete a namespace and every claim in it goes, taking the disks with it. No confirmation, no soft delete, no recycle bin.

Retain keeps everything and hands you the cleanup. Recycle still appears in the API and is deprecated:

The Recycle reclaim policy is deprecated. Instead, the recommended approach is to use dynamic provisioning.

Treat Recycle as a historical artifact. The real choice is Delete or Retain.

The Retain trap

Setting Retain protects the data and then produces the second-most-common storage support ticket. When the claim is deleted, the volume moves to Released, and:

the PersistentVolume still exists and the volume is considered "released". But it is not yet available for another claim because the previous claimant's data remains on the volume.

A Released PV will not bind to a new claim. Not to an identical claim, not to one with the same name in the same namespace. The blocker is the claimRef still pointing at the claim that no longer exists. Clearing it is what returns the volume to Available:

# The volume is Released and no new claim will touch it.
kubectl get pv
# NAME       CAPACITY   RECLAIM POLICY   STATUS     CLAIM
# pv-data    100Gi      Retain           Released   databases/postgres-data

# Drop the stale binding to make it Available again.
kubectl patch pv pv-data -p '{"spec":{"claimRef": null}}'

The data on the volume is untouched by this. You are only removing the record of a binding to a claim that has been deleted.

Why your PVC is stuck in Terminating

You run kubectl delete pvc, the command returns, and the claim sits in Terminating indefinitely. Nothing is broken. This is Storage Object in Use Protection doing its job:

If a user deletes a PVC in active use by a Pod, the PVC is not removed immediately. PVC removal is postponed until the PVC is no longer actively used by any Pods.

The mechanism is a finalizer. Two exist, and their exact names are worth knowing because they show up in kubectl describe:

• kubernetes.io/pvc-protection on claims
• kubernetes.io/pv-protection on volumes

Why your pod is stuck in Pending

The other half of the stuck-object family, and this one is a StorageClass setting.

volumeBindingMode has two values. Immediate is the default and binds as soon as the claim is created. WaitForFirstConsumer delays binding until a pod actually needs the volume.

That delay is not laziness, it is topology. With Immediate, upstream notes that PVs "will be bound or provisioned without knowledge of the Pod's scheduling requirements", which "can result in unschedulable Pods". In plain terms: on a cloud with zones, an Immediate claim can provision a disk in eu-west-1a while the only node with capacity for your pod is in eu-west-1b. The disk cannot cross the zone boundary, the pod cannot be scheduled, and it waits forever.

WaitForFirstConsumer inverts the order. The scheduler picks a node first, then the volume is provisioned to match. If you run a multi-zone cluster, this is almost always what you want:

apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: fast-ssd
provisioner: ebs.csi.aws.com
volumeBindingMode: WaitForFirstConsumer

The diagnostic is quick. A pod in Pending with a claim in Pending and no provisioning events points at topology or at a missing default StorageClass. A pod in Pending with a claim already Bound points at the node the volume landed on.

Expansion only goes one way

Volume expansion has been stable since v1.24 and works like this: you edit the claim, requesting more, and the backing volume grows.

You can only use the volume expansion feature to grow a Volume, not to shrink it.

Two conditions and one trap.

The conditions: the StorageClass needs allowVolumeExpansion: true, and the CSI driver has to support resize. Without the first, the API rejects the edit.

The trap is that expansion is driven by the difference between the claim and the volume, so closing that gap by hand disables it:

Directly editing the size of a PersistentVolume can prevent an automatic resize of that volume. If you edit the capacity of a PersistentVolume, and then edit the .spec of a matching PersistentVolumeClaim to make the size of the PersistentVolumeClaim match the PersistentVolume, then no storage resize happens. The Kubernetes control plane will see that the desired state of both resources matches, conclude that the backing volume size has been manually increased and that no resize is necessary.

So the correct move is to edit the PVC and nothing else:

# Right: ask for more on the claim, let the controller do the rest.
kubectl patch pvc postgres-data -p '{"spec":{"resources":{"requests":{"storage":"200Gi"}}}}'

Since shrinking is impossible, over-provisioning a volume is a decision you cannot walk back. The only route down is to create a smaller volume and copy the data across.

StatefulSets: the claims outlive the workload

Deployments and StatefulSets treat storage completely differently, which is most of the reason StatefulSets exist. If that distinction is still fuzzy, Kubernetes Deployments vs StatefulSets covers it directly.

A StatefulSet's volumeClaimTemplates generate one claim per replica, named <template-name>-<statefulset-name>-<ordinal>. A template called www in a StatefulSet called web produces www-web-0, www-web-1, www-web-2. That naming is the mechanism behind stable identity: when web-1 is rescheduled, it is reattached to www-web-1 and gets its own data back rather than a fresh disk.

The behaviour that surprises people is what happens on scale-down and delete:

Deleting and/or scaling a StatefulSet down will not delete the volumes associated with the StatefulSet. This is done to ensure data safety, which is generally more valuable than an automatic purge of all related StatefulSet resources.

Scale from 5 to 3 and two claims stay behind, still billed, still holding data. Scale back to 5 and those same claims are picked up again, which is exactly what you want for a database and exactly what you do not want for a cache you have been scaling for a year.

To change it, set persistentVolumeClaimRetentionPolicy, which reached GA in Kubernetes v1.32:

apiVersion: apps/v1
kind: StatefulSet
metadata:
  name: web
spec:
  persistentVolumeClaimRetentionPolicy:
    whenDeleted: Retain   # keep the data if someone deletes the StatefulSet
    whenScaled: Delete    # but reclaim it when scaling down
  replicas: 3
  volumeClaimTemplates:
    - metadata:
        name: www
      spec:
        accessModes: [ "ReadWriteOnce" ]
        storageClassName: fast-ssd
        resources:
          requests:
            storage: 10Gi

whenDeleted: Retain with whenScaled: Delete is a sensible pairing for most stateful workloads: scaling in is routine and reversible, deleting the StatefulSet is usually a mistake.

Reading the state of a volume

Four phases, and each one tells you which half of the system to look at:

Phase	Meaning	Where to look
Available	Free, not bound to a claim	Nothing wrong; no claim matches it yet
Bound	Attached to a claim	Normal steady state
Released	Claim deleted, storage not yet reclaimed	A Retain volume needing its claimRef cleared
Failed	Automated reclamation failed	The CSI driver logs

A Released volume on a Delete policy that never disappears usually means the driver could not remove the backing disk, often because it was deleted out from under Kubernetes in the cloud console.

A checklist worth running against your cluster

None of this needs a rewrite of anything. It is four commands and a decision.

# 1. What is the default StorageClass, and does it delete data?
kubectl get storageclass -o custom-columns=\
'NAME:.metadata.name,RECLAIM:.reclaimPolicy,EXPAND:.allowVolumeExpansion,BINDING:.volumeBindingMode,DEFAULT:.metadata.annotations.storageclass\.kubernetes\.io/is-default-class'

# 2. Which volumes would take their disks with them?
kubectl get pv -o custom-columns='NAME:.metadata.name,POLICY:.spec.persistentVolumeReclaimPolicy,STATUS:.status.phase,CLAIM:.spec.claimRef.name'

# 3. Anything already stranded?
kubectl get pv --field-selector status.phase=Released

# 4. Claims nobody is using, quietly costing money
kubectl get pvc --all-namespaces

If step 1 shows Delete on the default class, that is the setting to think hardest about. The annotation that marks a class as default is storageclass.kubernetes.io/is-default-class: "true", and the reclaim policy on a StorageClass cannot be changed after creation, so the fix is a new class rather than an edit.

Note that a PV's reclaim policy can be patched in place, which is the fastest way to protect volumes that already exist:

kubectl patch pv pv-data -p '{"spec":{"persistentVolumeReclaimPolicy":"Retain"}}'

Summary

The object model is the easy half. A PVC is demand, a PV is supply, a StorageClass is the recipe, and a CSI driver does the work. Bind one-to-one, mount by claim name, done.

The half that decides whether you keep your data is the lifecycle, and it comes down to a few rules that are not obvious from the YAML:

• ReadWriteOnce is a node constraint, and access modes other than ReadWriteOncePod are not enforced at all
• reclaimPolicy defaults to Delete, so on an untouched cluster deleting a claim deletes the disk
• Retain leaves the volume in Released, and it stays unusable until claimRef is cleared
• Finalizers holding a Terminating PVC are protecting a volume that is still mounted, so find the pod rather than patching the finalizer away
• Expansion grows and never shrinks, and hand-editing PV capacity silently disables it
• StatefulSet claims survive scale-down and deletion unless persistentVolumeClaimRetentionPolicy says otherwise

For the wider operational picture around these objects, Real-World Kubernetes Deployments covers the neighbouring concerns: probes, resource limits and disruption budgets.

FAQ

Can two pods share one PersistentVolumeClaim?
Yes, if they land on the same node or if the volume is ReadWriteMany with a driver that supports it. What you cannot do is bind two claims to one volume, since binding is strictly one-to-one.

Does deleting a namespace delete the underlying disks?
It deletes every PVC in that namespace. Whether the disks go with them depends on the reclaim policy of each PV, which for dynamically provisioned volumes is inherited from the StorageClass and defaults to Delete.

Why is my PVC Pending with no events?
Usually no default StorageClass, or a storageClassName naming a class that does not exist. If the class uses WaitForFirstConsumer, Pending is also the correct state until a pod actually references the claim.

Can I change a PVC's access mode after creating it?
Not in place for the general case. The supported route for moving to ReadWriteOncePod is documented as a task upstream, and it involves the PV rather than editing the claim's mode directly.

Is it safe to delete a PV that shows as Released?
Only once you are certain the data is not needed, or the policy is Retain and you have copied it. On Retain the storage asset in the cloud survives the PV object, so deleting the PV does not free the disk or stop the bill.

Do I still need to care about in-tree volume plugins?
Mostly no. The cloud providers' in-tree plugins have been migrated to CSI, and new drivers are CSI only. It matters when reading older manifests, where a spec.awsElasticBlockStore block signals something worth modernising.
