Terraform Module Outputs, Inputs and Sources: How Modules Pass Data to Each Other

A Terraform module is a box with a very small door. Everything inside it (resources, locals, data sources) is private. The only way in is an input variable, and the only way out is an output. Once that clicks, most module questions answer themselves: "how do I reference the instance my module created?", "how do I give this module my VPC?", "why can't I see module.app.aws_instance.web?"

This post walks through the module questions that come up most in real projects: outputs, passing values and whole resources between modules, modules with for_each, Git sources pinned to a branch or tag, and the provider error people hit when they refactor old modules. Every command in the terminal blocks was run on Terraform 1.15.8 with the built-in terraform_data resource and the random provider, so you can repeat them without a cloud account.

TLDR

• A module exposes values only through output blocks. From the caller you read them as module.<name>.<output>. You cannot reach into a module's resources directly.
• To pass data into a module, declare a variable in the module and set it in the module block. That is how you "pass a resource" too: pass its attributes, or the whole object with a typed variable.
• Referencing module.network.vpc_id from another module creates the dependency automatically. No depends_on needed.
• A module with for_each becomes a map of instances: module.network["production"].vpc_id, or a for expression to collect them all.
• Git module sources take ?ref= with a branch, tag or commit. Use tags or commits for anything shared, branches only while developing.
• "Provider configuration not present" means Terraform needs a provider configuration that is gone, most often because a module with its own provider block was removed while its resources are still in state. Move provider blocks to the root, apply, then remove the module.

Prerequisites

• Terraform 1.4 or later for the examples (they use the built-in terraform_data resource; we ran them on 1.15), and 1.7 or later for the removed block mentioned at the end
• A root configuration with at least one local module, or the Terraform terminal simulator to practice the basics first
• For the Git source section, access to a Git repository that holds a module

The layout used in this post

.
├── main.tf              # root module: calls the child modules
└── modules
    ├── network
    │   └── main.tf      # creates a "VPC", outputs its id and CIDR
    └── app
        └── main.tf      # takes a vpc_id input, creates a "server"

Get a value out of a module: outputs

Inside the module, an output block decides what the caller can see:

# modules/network/main.tf
variable "name" { type = string }
variable "cidr" { type = string }

resource "terraform_data" "vpc" {
  input = { name = var.name, cidr = var.cidr }
}

output "vpc_id" {
  description = "ID of the network, for modules that need to attach to it"
  value       = terraform_data.vpc.id
}

output "cidr" {
  value = var.cidr
}

In the caller, the module's outputs are attributes of module.<name>. That is the only view you get. Try to reach past it, to the resource itself, and Terraform refuses:

The error message is the whole lesson: module.app is object with 1 attribute "server_id". If the caller needs something, the module has to output it.

A few habits make outputs easier to live with:

• Output IDs and names, not whole resources, by default. Callers then depend on a small, stable interface instead of every attribute of a resource type.
• Add description. It shows up in module documentation generators and in the registry.
• Mark secrets sensitive = true. Terraform then hides the value in plan and apply output. The value is still stored in state, so that does not make it safe to share state.
• You can output a whole object when the caller genuinely needs many attributes: value = aws_instance.web gives the caller module.app.web.private_ip, module.app.web.arn and so on, at the cost of a wider interface.

Pass a resource into a module: inputs

There is no way to hand a module "the resource" as a live link. You pass values through variables, and Terraform tracks the dependency for you.

The common case is a single attribute:

# modules/app/main.tf
variable "vpc_id" {
  description = "Network the server attaches to"
  type        = string
}

resource "terraform_data" "server" {
  input = "server in ${var.vpc_id}"
}

output "server_id" {
  value = terraform_data.server.id
}

# main.tf
module "app" {
  source = "./modules/app"
  vpc_id = module.network["production"].vpc_id # an output of another module
}

When a module needs several attributes of the same resource, pass them together as an object instead of five separate variables:

variable "network" {
  type = object({
    id   = string
    cidr = string
  })
}

module "app" {
  source  = "./modules/app"
  network = {
    id   = module.network["production"].vpc_id
    cidr = module.network["production"].cidr
  }
}

You can even pass a whole resource object into a variable, as long as the object type matches its attribute names. An aws_vpc has id and cidr_block, so the variable would be object({ id = string, cidr_block = string }) and the caller writes network = aws_vpc.main; Terraform keeps the attributes the type names and discards the rest. type = any also works. The typed object is better: it documents exactly which attributes the module relies on, and the error messages are clearer when something does not fit.

Chain modules: one module's output as another's input

The module "app" block above already chains two modules. Because it reads module.network["production"].vpc_id, Terraform knows that everything in module.app that uses the value depends on the network. You do not need depends_on. Reach for depends_on on a module only for dependencies Terraform cannot see from references, and even then prefer passing a real value: depends_on on a module makes every resource in it wait for everything it depends on, which can make plans noisier.

The pattern scales to longer chains, network to database to application, with each module taking the previous one's outputs as inputs. Keep the chain in the root module. A child module that calls another module to get at a third one's outputs is usually a sign that the boundaries are wrong.

Modules with for_each: outputs become a map

Put for_each on a module block and you get one instance per key:

module "network" {
  source   = "./modules/network"
  for_each = {
    staging    = "10.10.0.0/16"
    production = "10.20.0.0/16"
  }
  name = each.key
  cidr = each.value
}

output "vpc_ids" {
  value = { for env, net in module.network : env => net.vpc_id }
}

output "app_server" {
  value = module.app.server_id
}

module.network is now a map of module instances. Index it with a key to read one (module.network["production"].vpc_id), or loop over it with a for expression to collect an output from every instance. Here is the whole configuration applied:

The same for expression works for count modules with a list instead of a map: [for net in module.network : net.vpc_id]. If you need the values as a list from a for_each module, wrap it: values(module.network)[*].vpc_id.

Module sources: pin a Git branch, tag or commit

Local paths are fine inside one repository. When several repositories share a module, keep it in Git and point source at it. The ref query parameter selects what to check out:

module "network" {
  # a release tag: what production should use (if your tags are never moved)
  source = "git::https://github.com/acme/terraform-modules.git//network?ref=v1.4.0"
}

module "network_dev" {
  # a branch: moves every time someone pushes, fine while you develop the module
  source = "git::https://github.com/acme/terraform-modules.git//network?ref=feature/ipv6"
}

module "network_pinned" {
  # a full commit SHA: cannot move at all
  source = "git::https://github.com/acme/terraform-modules.git//network?ref=4f2a9c1e8b7d6a5f4e3d2c1b0a9f8e7d6c5b4a39"
}

Details that trip people up:

• The double slash (.git//network) selects a subdirectory of the repository. Without it, Terraform uses the repository root.
• Private repositories over SSH use git::ssh://[email protected]/acme/terraform-modules.git//network?ref=v1.4.0, or the shorter [email protected]:acme/terraform-modules.git//network?ref=v1.4.0. The machine running Terraform (including CI) needs a key that can read the repository.
• Branch sources do not update on their own. A repeat terraform init keeps the modules already in .terraform/modules as long as their source is unchanged. To pick up new commits on the branch, run terraform get -update (modules only) or terraform init -upgrade (modules, and it also reconsiders provider versions). A fresh checkout, like a CI runner, downloads whatever the branch points at right now. That is exactly why production should not point at a branch: two runs of the same commit of your root configuration can use different module code.
• Tags can move. Git lets someone delete a tag and create it again on another commit. If nobody in your organisation re-tags releases, a tag is a good pin; if you cannot be sure, pin the full commit SHA.
• Version constraints (version = "~> 1.4") only work with registry sources, not with Git URLs. With Git, the ref is your version pin.

"Provider configuration not present" when you refactor modules

This one surprises people because it appears after deleting code, not adding it. Older modules often declared their own provider block inside the module. Here is one:

# modules/legacy/main.tf
terraform {
  required_providers {
    random = { source = "hashicorp/random" }
  }
}

# a provider block inside a child module: the legacy pattern
provider "random" {}

resource "random_pet" "name" {}

Everything works until you remove the module "legacy" block from the root to get rid of it. Terraform wants to destroy random_pet.name, but the provider configuration it needs to do that lived inside the module you just deleted:

The fix is to separate the two changes. First move the provider configuration to the root and delete the provider block from the module. Child modules inherit the root's default provider configurations automatically, so the module keeps working. Apply that on its own:

# main.tf (root)
provider "random" {}

module "legacy" {
  source = "./modules/legacy"
}

Now removing the module is a normal destroy. If you want Terraform to forget the resources instead of destroying them, put a removed block in place of the module (from = module.legacy with destroy = false); our Terraform state post covers removed and moved in detail.

Two rules keep you out of this for good:

1. No provider blocks in reusable modules. A module declares what it needs in required_providers; the root decides how providers are configured.
2. When a module needs a non-default provider, for example a second AWS region, pass it explicitly from the root:

provider "aws" {
  alias  = "eu"
  region = "eu-west-1"
}

module "backup_bucket" {
  source = "./modules/bucket"
  providers = {
    aws = aws.eu
  }
}

For the bigger picture of sharing providers and variables between many modules, see how to share providers and variables across Terraform modules.

Summary

Question	Answer
How do I read a value from a module?	Add an output in the module, read module.<name>.<output>
Can I reference a resource inside a module directly?	No, only its outputs
How do I pass a resource into a module?	Pass its attributes, or a typed object, through a variable
Do chained modules need depends_on?	No, references create the dependency
How do I read outputs from a for_each module?	module.x["key"].output, or a for expression over module.x
Branch, tag or commit as a Git source?	Tag or commit for shared code, branch only while developing
"Provider configuration not present"?	Move the provider to the root, apply, then remove the module

Modules stay pleasant to work with when their interface is small and explicit: a few typed variables in, a few described outputs out, no provider blocks inside. For the language features that go into those interfaces, Terraform variables, loops and outputs is the next read, and for laying modules out across environments, see how to organize Terraform modules for multiple environments.
