Base64 Explained: 3 Bytes In, 4 Characters Out, Zero Secrecy

Base64 is in more of your config than you think. Kubernetes Secrets store their values in it, a signed JWT in an Authorization header is three base64url strings joined by dots, kubeconfig files carry certificates in it, and CI systems ask you to paste base64 when a file has to fit in a variable. Most of the time it works. When it does not, the bug is usually small, like an extra newline or a value encoded twice, and it takes an afternoon to find because the broken value looks almost the same as the right one.

This post shows how base64 works, why its output is a third bigger, and what it does not protect. Then it walks through the bugs that keep coming back. Every command and output below comes from a real run.

TLDR

• Base64 maps every 3 bytes to 4 characters from a 64-character alphabet. Anyone can reverse it with one command. It is an encoding, not encryption.
• A Kubernetes Secret's data field is plain base64. kubectl get secret -o yaml plus base64 -d shows the value to anyone with read access.
• The output is 33.3% bigger than the input. GNU base64 also adds a newline every 76 characters, which makes it 35.1%. Gzip wins most of it back on the wire.
• The common bugs: a trailing newline from echo, wrapped output pasted into YAML or an env var, double encoding with --from-literal or stringData, and the URL-safe alphabet without padding in JWTs.

Prerequisites

• A Linux shell with GNU coreutils for base64 and basenc. We used coreutils 9.1 on Debian 12.
• openssl and python3 for the JWT and comparison examples.
• kubectl for the Secret examples. Every kubectl command here uses --dry-run=client, so you do not need a cluster. We used kubectl v1.37.1.

How base64 turns 3 bytes into 4 characters

Base64 uses 64 symbols, and 64 is 2 to the power of 6, so each output character carries exactly 6 bits. Three bytes are 24 bits, and 24 bits split cleanly into four 6-bit groups. That is the whole algorithm: take 3 bytes, cut them into four 6-bit numbers, and look each number up in the alphabet.

This script prints each step for the string k8s:

import base64

data = b"k8s"
bits = "".join(f"{b:08b}" for b in data)
groups = [bits[i:i + 6] for i in range(0, len(bits), 6)]

print("bytes   ", " ".join(f"{b:08b}" for b in data))
print("6 bits  ", " ".join(groups))
print("values  ", " ".join(str(int(g, 2)) for g in groups))
print("base64  ", base64.b64encode(data).decode())

bytes    01101011 00111000 01110011
6 bits   011010 110011 100001 110011
values   26 51 33 51
base64   azhz

The standard alphabet from RFC 4648 is:

 0-25   A B C ... Z
26-51   a b c ... z
52-61   0 1 2 ... 9
62      +
63      /

So 26 is a, 51 is z and 33 is h, and k8s becomes azhz. Decoding runs the same steps backwards. There is no key and nothing to guess, which is why base64 is not a way to hide anything.

Padding: what the = signs mean

When the input length is not a multiple of 3, the last group is short. Base64 fills the missing bits with zeros and adds = so the output length stays a multiple of 4:

printf 'k' | base64
printf 'k8' | base64
printf 'k8s' | base64

aw==
azg=
azhz

One leftover byte gives 2 characters plus ==. Two leftover bytes give 3 characters plus =. Padding carries no data, which is why some formats, JWT among them, drop it. That saves a few bytes and causes a bug we will get to below.

Because the mapping is fixed, common inputs have recognizable prefixes. JSON that starts with {" followed by a letter encodes to a string starting with eyJ, so eyJ... is almost always JSON, often a JWT. Base64-encoded PEM text (-----BEGIN ...) starts with LS0tLS1CRUdJTi.

The 33% overhead, measured

Every 3 input bytes become 4 output characters, so the encoded size is 4 × ceil(n / 3). For large inputs that is 4/3 of the original, an overhead of 33.3%. GNU base64 also wraps its output at 76 characters by default, which adds one newline for every 76 characters.

We encoded 1 MiB of random data to check the math:

head -c 1048576 /dev/urandom > blob.bin
wc -c < blob.bin
base64 blob.bin | wc -c        # default: wrapped at 76 characters
base64 -w0 blob.bin | wc -c    # -w0: no wrapping
base64 blob.bin | wc -l

1048576
1416501
1398104
18397

The formula gives the same numbers: 4 × ceil(1048576 / 3) is 1,398,104 characters, and ceil(1398104 / 76) is 18,397 lines, each ending in a newline, for 1,416,501 bytes in total. That is 1.3333 times the input without wrapping and 1.3509 times with it.

On the wire, compression gets most of it back. Base64 only uses 6 of every 8 bits, and gzip notices:

gzip -9 -c blob.bin | wc -c
base64 -w0 blob.bin | gzip -9 | wc -c

1048763
1058004

For this sample, gzip cut the overhead from 33.3% to 0.9%. The overhead still counts wherever the encoded size is what matters: memory, environment variables, cookies and request headers. A JWT is sent in a header on every call, and header size limits apply to its encoded form: each claim costs 4/3 of its size, and nginx's default large_client_header_buffers allows 8 KB per header line.

Kubernetes Secrets are base64, not encryption

A Secret's data field holds base64 strings. Create one locally to see what the API server would store:

kubectl create secret generic db-creds \
  --from-literal=username=app \
  --from-literal=password='hunter2-prod' \
  --dry-run=client -o yaml

apiVersion: v1
data:
  password: aHVudGVyMi1wcm9k
  username: YXBw
kind: Secret
metadata:
  name: db-creds

Getting the value back takes one pipe. On a cluster you would use kubectl get secret db-creds -o jsonpath='{.data.password}'; here we read the same field from the dry run:

kubectl create secret generic db-creds --from-literal=password='hunter2-prod' \
  --dry-run=client -o jsonpath='{.data.password}' | base64 -d; echo

hunter2-prod

Base64 is there so binary data such as keystores and TLS keys fits inside JSON and YAML. It does nothing for secrecy.

For a longer walkthrough, see How to Decode a Kubernetes Secret and the ConfigMaps and Secrets part of our Kubernetes guide.

Bug 1: the newline from echo

echo adds a newline, and base64 encodes it like any other byte:

echo 'hunter2-prod' | base64
printf '%s' 'hunter2-prod' | base64

aHVudGVyMi1wcm9kCg==
aHVudGVyMi1wcm9k

The first value ends in Cg==, which is the encoded \n. Decode it and look at the bytes:

echo 'aHVudGVyMi1wcm9kCg==' | base64 -d | od -c

0000000   h   u   n   t   e   r   2   -   p   r   o   d  \n
0000015

Put that value in a Secret and the password is now hunter2-prod plus a newline. The app sends 13 bytes, the database expects 12, and you get an authentication error for a password that looks right in every log line.

The same thing happens with files. A file written with echo ends in a newline, and --from-file keeps it:

echo 'hunter2-prod' > password.txt
kubectl create secret generic db-creds --from-file=password=password.txt \
  --dry-run=client -o jsonpath='{.data.password}'; echo

printf '%s' 'hunter2-prod' > password.txt
kubectl create secret generic db-creds --from-file=password=password.txt \
  --dry-run=client -o jsonpath='{.data.password}'; echo

aHVudGVyMi1wcm9kCg==
aHVudGVyMi1wcm9k

Use printf '%s' whenever the exact bytes matter, and pipe a suspect value through base64 -d | od -c to see the last byte.

Bug 2: wrapped output in YAML and env vars

GNU base64 breaks its output into 76-character lines. A database URL is long enough to hit that:

DB_URL='postgresql://app:[email protected]:5432/orders?sslmode=require'
printf '%s' "$DB_URL" | wc -c
printf '%s' "$DB_URL" | base64

69
cG9zdGdyZXNxbDovL2FwcDpodW50ZXIyLXByb2RAZGIuaW50ZXJuYWw6NTQzMi9vcmRlcnM/c3Ns
bW9kZT1yZXF1aXJl

Now put it into a manifest the way many scripts do, with a heredoc:

cat <<EOF > secret.yaml
apiVersion: v1
kind: Secret
metadata:
  name: db-url
data:
  url: $(printf '%s' "$DB_URL" | base64)
EOF
kubectl create --dry-run=client -f secret.yaml -o yaml

error: error parsing secret.yaml: error converting YAML to JSON: yaml: line 8: could not find expected ':'

The second line of the value landed at column 0, and YAML read it as a new key. In an env var or a CI variable the newline does not fail this loudly: it ends up inside the value. Turn wrapping off with -w0:

cat <<EOF > secret.yaml
apiVersion: v1
kind: Secret
metadata:
  name: db-url
data:
  url: $(printf '%s' "$DB_URL" | base64 -w0)
EOF
sed -n 's/^  url: //p' secret.yaml | base64 -d

postgresql://app:[email protected]:5432/orders?sslmode=require

Even simpler: let kubectl create secret generic db-url --from-literal=url="$DB_URL" --dry-run=client -o yaml write the manifest, and the encoding is never your problem.

macOS and openssl

macOS ships a different base64. According to its man page, it does not wrap by default (-b sets a line length, and -w is accepted for GNU compatibility). Older macOS releases decode only with -D, and on them -d is a debug flag. A script that has to run on both should encode with a pipe that works everywhere:

printf '%s' "$DB_URL" | base64 | tr -d '\n'

cG9zdGdyZXNxbDovL2FwcDpodW50ZXIyLXByb2RAZGIuaW50ZXJuYWw6NTQzMi9vcmRlcnM/c3NsbW9kZT1yZXF1aXJl

openssl base64 is another option, but it wraps at 64 characters and has a sharper edge when decoding:

printf '%s' "$DB_URL" | openssl base64
printf '%s' "$DB_URL" | base64 -w0 | openssl base64 -d | wc -c; echo "rc=${PIPESTATUS[2]}"
printf '%s' "$DB_URL" | base64 -w0 | openssl base64 -d -A; echo

cG9zdGdyZXNxbDovL2FwcDpodW50ZXIyLXByb2RAZGIuaW50ZXJuYWw6NTQzMi9v
cmRlcnM/c3NsbW9kZT1yZXF1aXJl
0
rc=0
postgresql://app:[email protected]:5432/orders?sslmode=require

Without -A, OpenSSL 3.0 decoded our 92-character single line to zero bytes and exit code 0. No error, just an empty value. If you use openssl base64 for single-line data, pass -A both ways.

Bug 3: double encoding

--from-literal, --from-file and stringData all take plain text and encode it for you. Give them a value that is already encoded and it gets encoded again:

kubectl create secret generic db-creds \
  --from-literal=password="$(printf '%s' 'hunter2-prod' | base64)" \
  --dry-run=client -o jsonpath='{.data.password}'; echo

kubectl create secret generic db-creds \
  --from-literal=password="$(printf '%s' 'hunter2-prod' | base64)" \
  --dry-run=client -o jsonpath='{.data.password}' | base64 -d; echo

YUhWdWRHVnlNaTF3Y205aw==
aHVudGVyMi1wcm9k

The pod now gets aHVudGVyMi1wcm9k as its password. The giveaway is a first decode that looks like base64 instead of the value you stored. Decode it again to confirm:

echo 'YUhWdWRHVnlNaTF3Y205aw==' | base64 -d | base64 -d; echo

hunter2-prod

The rule: data takes base64, and stringData, --from-literal and --from-file take the raw value. In a Helm chart, b64enc belongs in data:, never in stringData:.

Not every double encoding is a bug. PEM is itself base64 with header lines, so a TLS Secret's tls.crt field is encoded twice on purpose:

openssl req -x509 -newkey ec -pkeyopt ec_paramgen_curve:P-256 -nodes \
  -keyout tls.key -out tls.crt -days 30 -subj '/CN=orders.internal' 2>/dev/null
kubectl create secret tls orders-tls --cert=tls.crt --key=tls.key \
  --dry-run=client -o jsonpath='{.data.tls\.crt}' | cut -c1-40
kubectl create secret tls orders-tls --cert=tls.crt --key=tls.key \
  --dry-run=client -o jsonpath='{.data.tls\.crt}' | base64 -d | head -2

LS0tLS1CRUdJTiBDRVJUSUZJQ0FURS0tLS0tCk1J
-----BEGIN CERTIFICATE-----
MIIBijCCAS+gAwIBAgIUazfeROKqRj7HLheO41+kH88CZagwCgYIKoZIzj0EAwIw

That LS0tLS1CRUdJTi prefix is the -----BEGIN from earlier. The certificate-authority-data field in a kubeconfig works the same way.

base64url and JWTs

Two characters of the standard alphabet cause trouble outside of files. + means a space in a form-encoded query string, and / is a path separator. RFC 4648 defines a second alphabet, base64url, that uses - and _ instead:

printf '\xfb\xff\xbf' | base64
printf '\xfb\xff\xbf' | basenc --base64url

+/+/
-_-_

This is not only about odd bytes. The database URL from earlier encodes to ...cnM/c3Ns... in standard base64 and ...cnM_c3Ns... in base64url. In a URL path, that / splits the value in two.

JWTs use base64url and also drop the = padding (RFC 7515). This script, saved as make-jwt.sh, builds a real HS256 token with shell tools:

#!/usr/bin/env bash
set -euo pipefail

b64url() { basenc --base64url -w0 | tr -d '='; }

header=$(printf '%s' '{"alg":"HS256","typ":"JWT"}' | b64url)
payload=$(printf '%s' '{"sub":"deploy-bot","role":"admin","exp":1793318400}' | b64url)
signature=$(printf '%s' "$header.$payload" \
  | openssl dgst -sha256 -hmac 'not-a-real-key' -binary | b64url)

echo "$header.$payload.$signature"

eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9.eyJzdWIiOiJkZXBsb3ktYm90Iiwicm9sZSI6ImFkbWluIiwiZXhwIjoxNzkzMzE4NDAwfQ.mirpAmeTzGcS59Fo6JImIz4IBPSFSqpDJy1qltzzzuA

Both JSON parts start with eyJ. Now try to read the payload the obvious way:

chmod +x make-jwt.sh
TOKEN=$(./make-jwt.sh)
echo "$TOKEN" | cut -d. -f2 | base64 -d; echo " rc=$?"

{"sub":"deploy-bot","role":"admin","exp":1793318400}base64: invalid input
 rc=1

The payload part is 70 characters, not a multiple of 4, so GNU base64 prints what it could decode and then exits with 1. The JSON looks complete, which makes this easy to miss: under set -e the script stops here, and without it the script carries on with output that may be cut short. basenc --base64url -d fails the same way, because it also expects padding. Translate the alphabet and put the padding back first:

b64url_decode() {
  local s
  s=$(tr '_-' '/+')               # back to the standard alphabet
  case $(( ${#s} % 4 )) in        # put the stripped padding back
    2) s="$s==" ;;
    3) s="$s=" ;;
  esac
  printf '%s' "$s" | base64 -d
}

echo "$TOKEN" | cut -d. -f2 | b64url_decode; echo
echo "$TOKEN" | cut -d. -f1 | b64url_decode; echo

{"sub":"deploy-bot","role":"admin","exp":1793318400}
{"alg":"HS256","typ":"JWT"}

In Python, base64.urlsafe_b64decode(part + "=" * (-len(part) % 4)) does the same in one line.

Anyone holding a signed JWT like this one can read its claims, because they are only base64url. The signature stops people from changing them, not from reading them, so never put a secret in a JWT payload. (Encrypted JWTs, JWE, are a different format with five parts.) For a quick look at a token, our JWT decoder runs in the browser, and the base64 tool does the same for plain values.

Data URIs

A data URI puts a whole file inside a URL: data:<media type>;base64,<data>. Browsers then skip the extra request. We built one from this site's 180x180 Apple touch icon, saved as icon.png:

wc -c < icon.png

1167
1578

1,167 bytes became 1,578 characters: the 33% plus the 22-character prefix. Use -w0 again so the URI stays on one line in HTML or CSS. The image also loses its own cache entry and is downloaded again with every page or stylesheet that inlines it. That is fine for a few small icons and bad for anything large or shared across pages.


Summary

Base64 is a fixed mapping from bytes to 64 safe characters. It makes binary data fit in text formats, costs a third more space, and hides nothing. The bugs come from a short list of mistakes:

• Base64 does not protect Secrets. RBAC, encryption at rest and keeping values out of Git do.
• echo adds a newline. Use printf '%s' and check suspect values with base64 -d | od -c.
• GNU base64 wraps at 76 characters. Use -w0, or | tr -d '\n' where macOS is involved. With openssl base64, pass -A both ways.
• data takes base64; stringData, --from-literal and --from-file take raw values. If the first decode still looks like base64, check for double encoding.
• JWTs use base64url without padding. Swap -_ back to +/ and restore the = before decoding.
• Check the exit code of base64 -d. GNU prints partial output before it fails, and the Rust coreutils in Ubuntu 26.10 behave differently on bad input.
