// advent-of-devops/day-17

Day 17 of 25IntermediateServerless

Serverless Deploy

Deploy a serverless function to AWS Lambda with API Gateway, learning modern serverless architecture patterns.

Updated

Description

You need to deploy an API that scales automatically, has zero idle costs, and requires minimal infrastructure management. Enter serverless with AWS Lambda. Today you'll deploy a function-based API.

Task

Deploy a serverless API using AWS Lambda and API Gateway.

Requirements:

  • Create a Lambda function
  • Set up API Gateway endpoint
  • Deploy using Infrastructure as Code
  • Add environment variables
  • Test the deployed API

Target

  • ✅ Lambda function deployed
  • ✅ API Gateway endpoint working
  • ✅ Function triggered via HTTP
  • ✅ Logs visible in CloudWatch
  • ✅ Deployed via IaC

Sample App

Serverless Function

handler.js

'use strict';

module.exports.hello = async (event) => {
  const name = event.queryStringParameters?.name || 'World';

  console.log('Received request:', { name });

  return {
    statusCode: 200,
    headers: {
      'Content-Type': 'application/json',
      'Access-Control-Allow-Origin': '*'
    },
    body: JSON.stringify({
      message: `Hello, ${name}!`,
      timestamp: new Date().toISOString(),
      requestId: event.requestContext.requestId
    })
  };
};

module.exports.getUser = async (event) => {
  const userId = event.pathParameters?.id;

  // Simulate database lookup
  const user = {
    id: userId,
    name: 'John Doe',
    email: '[email protected]'
  };

  return {
    statusCode: 200,
    headers: {
      'Content-Type': 'application/json'
    },
    body: JSON.stringify(user)
  };
};

module.exports.createUser = async (event) => {
  const data = JSON.parse(event.body);

  console.log('Creating user:', data);

  // Validate input
  if (!data.name || !data.email) {
    return {
      statusCode: 400,
      body: JSON.stringify({
        error: 'Name and email are required'
      })
    };
  }

  // Simulate user creation
  const user = {
    id: Date.now().toString(),
    ...data,
    createdAt: new Date().toISOString()
  };

  return {
    statusCode: 201,
    headers: {
      'Content-Type': 'application/json'
    },
    body: JSON.stringify(user)
  };
};

View Solution

Solution

1. Serverless Framework Approach

serverless.yml

service: advent-serverless-api

frameworkVersion: '4'

provider:
  name: aws
  runtime: nodejs24.x
  region: us-east-1
  stage: ${opt:stage, 'dev'}
  memorySize: 256
  timeout: 10

  environment:
    STAGE: ${self:provider.stage}
    TABLE_NAME: ${self:custom.tableName}

  iam:
    role:
      statements:
        - Effect: Allow
          Action:
            - dynamodb:Query
            - dynamodb:Scan
            - dynamodb:GetItem
            - dynamodb:PutItem
            - dynamodb:UpdateItem
            - dynamodb:DeleteItem
          Resource:
            - Fn::GetAtt: [UsersTable, Arn]

  logs:
    restApi: true

functions:
  hello:
    handler: handler.hello
    events:
      - httpApi:
          path: /hello
          method: get

  getUser:
    handler: handler.getUser
    events:
      - httpApi:
          path: /users/{id}
          method: get

  createUser:
    handler: handler.createUser
    events:
      - httpApi:
          path: /users
          method: post

  listUsers:
    handler: handler.listUsers
    events:
      - httpApi:
          path: /users
          method: get

resources:
  Resources:
    UsersTable:
      Type: AWS::DynamoDB::Table
      Properties:
        TableName: ${self:custom.tableName}
        BillingMode: PAY_PER_REQUEST
        AttributeDefinitions:
          - AttributeName: id
            AttributeType: S
        KeySchema:
          - AttributeName: id
            KeyType: HASH

custom:
  tableName: users-${self:provider.stage}

plugins:
  - serverless-offline  # For local testing

package.json

{
  "name": "advent-serverless-api",
  "version": "1.0.0",
  "description": "Serverless API example",
  "main": "handler.js",
  "scripts": {
    "deploy": "serverless deploy",
    "remove": "serverless remove",
    "logs": "serverless logs -f hello -t",
    "local": "serverless offline"
  },
  "devDependencies": {
    "serverless": "^4.44.0",
    "serverless-offline": "^14.8.3"
  }
}

2. AWS SAM Approach

template.yaml

AWSTemplateFormatVersion: '2010-09-09'
Transform: AWS::Serverless-2016-10-31
Description: Serverless API with SAM

Globals:
  Function:
    Timeout: 10
    MemorySize: 256
    Runtime: nodejs24.x
    Environment:
      Variables:
        STAGE: !Ref Stage

Parameters:
  Stage:
    Type: String
    Default: dev
    AllowedValues:
      - dev
      - staging
      - prod

Resources:
  # API Gateway
  ApiGateway:
    Type: AWS::Serverless::Api
    Properties:
      StageName: !Ref Stage
      Cors:
        AllowMethods: "'GET, POST, PUT, DELETE, OPTIONS'"
        AllowHeaders: "'Content-Type,Authorization'"
        AllowOrigin: "'*'"

  # Lambda Functions
  HelloFunction:
    Type: AWS::Serverless::Function
    Properties:
      CodeUri: ./
      Handler: handler.hello
      Events:
        HelloApi:
          Type: Api
          Properties:
            RestApiId: !Ref ApiGateway
            Path: /hello
            Method: GET

  GetUserFunction:
    Type: AWS::Serverless::Function
    Properties:
      CodeUri: ./
      Handler: handler.getUser
      Policies:
        - DynamoDBReadPolicy:
            TableName: !Ref UsersTable
      Events:
        GetUserApi:
          Type: Api
          Properties:
            RestApiId: !Ref ApiGateway
            Path: /users/{id}
            Method: GET

  CreateUserFunction:
    Type: AWS::Serverless::Function
    Properties:
      CodeUri: ./
      Handler: handler.createUser
      Policies:
        - DynamoDBCrudPolicy:
            TableName: !Ref UsersTable
      Events:
        CreateUserApi:
          Type: Api
          Properties:
            RestApiId: !Ref ApiGateway
            Path: /users
            Method: POST

  # DynamoDB Table
  UsersTable:
    Type: AWS::DynamoDB::Table
    Properties:
      TableName: !Sub users-${Stage}
      BillingMode: PAY_PER_REQUEST
      AttributeDefinitions:
        - AttributeName: id
          AttributeType: S
      KeySchema:
        - AttributeName: id
          KeyType: HASH

Outputs:
  ApiUrl:
    Description: "API Gateway endpoint URL"
    Value: !Sub "https://${ApiGateway}.execute-api.${AWS::Region}.amazonaws.com/${Stage}"

  HelloFunction:
    Description: "Hello Lambda Function ARN"
    Value: !GetAtt HelloFunction.Arn

  UsersTableName:
    Description: "DynamoDB table name"
    Value: !Ref UsersTable

samconfig.toml

version = 0.1

[default.deploy.parameters]
stack_name = "advent-serverless-api"
region = "us-east-1"
capabilities = "CAPABILITY_IAM"
parameter_overrides = "Stage=dev"

3. Terraform Approach

main.tf

terraform {
  required_version = ">= 1.5"
  required_providers {
    aws = {
      source  = "hashicorp/aws"
      version = "~> 6.0"
    }
  }
}

provider "aws" {
  region = var.aws_region
}

# Lambda function
resource "aws_lambda_function" "hello" {
  filename      = "function.zip"
  function_name = "hello-${var.environment}"
  role          = aws_iam_role.lambda_role.arn
  handler       = "handler.hello"
  runtime       = "nodejs24.x"
  timeout       = 10
  memory_size   = 256

  environment {
    variables = {
      STAGE = var.environment
    }
  }

  source_code_hash = filebase64sha256("function.zip")
}

# IAM role for Lambda
resource "aws_iam_role" "lambda_role" {
  name = "lambda-role-${var.environment}"

  assume_role_policy = jsonencode({
    Version = "2012-10-17"
    Statement = [
      {
        Action = "sts:AssumeRole"
        Effect = "Allow"
        Principal = {
          Service = "lambda.amazonaws.com"
        }
      }
    ]
  })
}

# Attach CloudWatch Logs policy
resource "aws_iam_role_policy_attachment" "lambda_logs" {
  role       = aws_iam_role.lambda_role.name
  policy_arn = "arn:aws:iam::aws:policy/service-role/AWSLambdaBasicExecutionRole"
}

# API Gateway
resource "aws_apigatewayv2_api" "api" {
  name          = "serverless-api-${var.environment}"
  protocol_type = "HTTP"

  cors_configuration {
    allow_origins = ["*"]
    allow_methods = ["GET", "POST", "PUT", "DELETE"]
    allow_headers = ["content-type", "authorization"]
  }
}

# API Gateway integration
resource "aws_apigatewayv2_integration" "hello" {
  api_id           = aws_apigatewayv2_api.api.id
  integration_type = "AWS_PROXY"
  integration_uri  = aws_lambda_function.hello.invoke_arn
}

# API Gateway route
resource "aws_apigatewayv2_route" "hello" {
  api_id    = aws_apigatewayv2_api.api.id
  route_key = "GET /hello"
  target    = "integrations/${aws_apigatewayv2_integration.hello.id}"
}

# API Gateway stage
resource "aws_apigatewayv2_stage" "default" {
  api_id      = aws_apigatewayv2_api.api.id
  name        = var.environment
  auto_deploy = true
}

# Lambda permission for API Gateway
resource "aws_lambda_permission" "api_gateway" {
  statement_id  = "AllowExecutionFromAPIGateway"
  action        = "lambda:InvokeFunction"
  function_name = aws_lambda_function.hello.function_name
  principal     = "apigateway.amazonaws.com"
  source_arn    = "${aws_apigatewayv2_api.api.execution_arn}/*/*"
}

# Outputs
output "api_url" {
  value = aws_apigatewayv2_stage.default.invoke_url
}

output "function_name" {
  value = aws_lambda_function.hello.function_name
}

Explanation

Serverless Concepts

1. AWS Lambda

Event-driven compute:

HTTP Request → API Gateway → Lambda Function → Response

Pricing: Pay per request + compute time

Benefits:

  • No servers to manage
  • Auto-scaling
  • Pay-per-use
  • High availability built-in

2. API Gateway

Managed API service:

  • Handles HTTP requests
  • Routes to Lambda
  • Authentication/authorization
  • Rate limiting
  • CORS support

3. Cold Starts

First invocation slow:

  • Container initialization
  • Code loading
  • Connection setup

Mitigations:

  • Provisioned concurrency
  • Keep functions warm
  • Optimize package size

Lambda Event Structure

{
  "requestContext": {
    "requestId": "abc-123",
    "http": {
      "method": "GET",
      "path": "/hello"
    }
  },
  "headers": {
    "content-type": "application/json"
  },
  "queryStringParameters": {
    "name": "World"
  },
  "body": null
}

Response Format

{
  "statusCode": 200,
  "headers": {
    "Content-Type": "application/json"
  },
  "body": JSON.stringify({ message: "Success" })
}

Try to solve the challenge yourself first!

Click "Reveal Solution" when you're ready to see the answer.

Result

Deploy with Serverless Framework

# Install Serverless Framework (v4 asks you to log in on first use)
npm install -g serverless

# Install dependencies
npm install

# Deploy to AWS
serverless deploy --stage dev

# Output:
# Deploying advent-serverless-api to stage dev (us-east-1)
#
# ✔ Service deployed to stack advent-serverless-api-dev
#
# endpoints:
#   GET - https://abc123.execute-api.us-east-1.amazonaws.com/hello
#   GET - https://abc123.execute-api.us-east-1.amazonaws.com/users/{id}
#   POST - https://abc123.execute-api.us-east-1.amazonaws.com/users
#
# functions:
#   hello: advent-serverless-api-dev-hello
#   getUser: advent-serverless-api-dev-getUser
#   createUser: advent-serverless-api-dev-createUser

Deploy with AWS SAM

# Install AWS SAM CLI
brew install aws-sam-cli

# Build
sam build

# Deploy
sam deploy --guided

# Output:
# Successfully created/updated stack - advent-serverless-api
#
# CloudFormation outputs:
# ApiUrl: https://abc123.execute-api.us-east-1.amazonaws.com/dev
# HelloFunction: arn:aws:lambda:us-east-1:123456789:function:HelloFunction

Test the API

# Get API URL
API_URL=$(serverless info --verbose | grep "GET" | head -1 | awk '{print $NF}')

# Test hello endpoint
curl "$API_URL"
# {"message":"Hello, World!","timestamp":"2025-12-17T..."}

# Test with query parameter
curl "$API_URL?name=DevOps"
# {"message":"Hello, DevOps!","timestamp":"2025-12-17T..."}

# Test getUser endpoint
curl "https://abc123.execute-api.us-east-1.amazonaws.com/users/123"
# {"id":"123","name":"John Doe","email":"[email protected]"}

# Test createUser endpoint
curl -X POST \
  -H "Content-Type: application/json" \
  -d '{"name":"Jane","email":"[email protected]"}' \
  "https://abc123.execute-api.us-east-1.amazonaws.com/users"
# {"id":"1702820000000","name":"Jane","email":"[email protected]","createdAt":"2025-12-17T..."}

View Logs

# Serverless Framework
serverless logs -f hello -t

# AWS CLI
aws logs tail /aws/lambda/hello-dev --follow

# CloudWatch Logs Insights query
aws logs start-query \
  --log-group-name /aws/lambda/hello-dev \
  --start-time $(date -u -d '1 hour ago' +%s) \
  --end-time $(date +%s) \
  --query-string 'fields @timestamp, @message | filter @message like /ERROR/ | sort @timestamp desc'

Validation

Testing Checklist

# 1. Function deployed
aws lambda get-function --function-name hello-dev
# Should return function configuration

# 2. API Gateway exists
aws apigatewayv2 get-apis
# Should list your API

# 3. Endpoint responds
curl -I https://abc123.execute-api.us-east-1.amazonaws.com/hello
# Should return 200 OK

# 4. Logs visible
aws logs describe-log-groups --log-group-name-prefix /aws/lambda/hello
# Should show log group

# 5. Function can be invoked
aws lambda invoke \
  --function-name hello-dev \
  --payload '{"queryStringParameters":{"name":"Test"}}' \
  response.json
cat response.json
# Should show response

# 6. Metrics available
aws cloudwatch get-metric-statistics \
  --namespace AWS/Lambda \
  --metric-name Invocations \
  --dimensions Name=FunctionName,Value=hello-dev \
  --start-time $(date -u -d '1 hour ago' +%Y-%m-%dT%H:%M:%S) \
  --end-time $(date -u +%Y-%m-%dT%H:%M:%S) \
  --period 3600 \
  --statistics Sum

Best Practices

✅ Do's

  1. Use Infrastructure as Code: Serverless Framework, SAM, or Terraform
  2. Set appropriate timeouts: Default may be too long
  3. Monitor cold starts: Track performance
  4. Use environment variables: Configuration
  5. Enable logging: CloudWatch Logs
  6. Set memory appropriately: Affects CPU too

❌ Don'ts

  1. Don't put secrets in code: Use Parameter Store/Secrets Manager
  2. Don't make functions too large: Keep them focused
  3. Don't ignore costs: Monitor usage
  4. Don't skip error handling: Return proper status codes
  5. Don't forget CORS: Enable for web apps

Share Your Success

Deployed serverless? Share it!

Tag @thedevopsdaily on X with:

  • API endpoint (if public)
  • Response time
  • Cost estimate
  • What you built

Use hashtags: #AdventOfDevOps #Serverless #AWS #Lambda #Day17

Ready to complete this challenge?

Mark this challenge as complete once you've finished the task. We'll track your progress!

Completed this challenge? Share it.

Tag @thedevopsdaily and share it with the community.

Share on XShare on LinkedIn
Proudly Sponsored By

We earn commissions when you shop through the links below.

Bitrise

Bitrise

Managed runners for GitHub Actions

Bitrise Build Hub runs your GitHub Actions jobs on M4 Macs and AMD Linux machines. Change runs-on and keep your workflows, secrets and logs on GitHub.

Learn more
Atomsized

Atomsized

AWS platform engineering and GitOps

Design and automation for reliable AWS and Kubernetes platforms, safer delivery workflows, and preview and UAT environments your engineers can understand and own.

Learn more
DigitalOcean

DigitalOcean

Cloud infrastructure for developers

Simple, reliable cloud computing designed for developers

Learn more
DevDojo

DevDojo

Developer community & tools

Join a community of developers sharing knowledge and tools

Learn more
SMTPfast

SMTPfast

Developer-first email API

Send transactional and marketing email through a clean REST API. Detailed logs, webhooks, and embeddable signup forms in one dashboard.

Learn more
QuizAPI

QuizAPI

Developer-first quiz platform

Build, generate, and embed quizzes with a powerful REST API. AI-powered question generation and live multiplayer.

Learn more

Want to support DevOps Daily and reach thousands of developers?

Become a Sponsor

Found an issue?
