// advent-of-devops/day-16

Day 16 of 25IntermediateKubernetes

Autoscaling

Configure horizontal pod autoscaling in Kubernetes to automatically scale applications based on CPU and memory usage.

Updated

Description

Your application experiences variable load throughout the day. During peak hours, pods are overwhelmed. During off-hours, you're wasting resources. Configure autoscaling to automatically adjust pod count based on demand.

Task

Configure Horizontal Pod Autoscaler for a Kubernetes application.

Requirements:

  • Set up metrics server
  • Configure HPA based on CPU usage
  • Add custom metrics scaling
  • Test scaling behavior
  • Monitor scaling events

Target

  • ✅ HPA configured and active
  • ✅ Pods scale up under load
  • ✅ Pods scale down when idle
  • ✅ Metrics server running
  • ✅ Scaling thresholds optimized

Sample App

Application with Load Generation

app.yaml

apiVersion: v1
kind: Namespace
metadata:
  name: autoscale-demo
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: web-app
  namespace: autoscale-demo
spec:
  replicas: 2
  selector:
    matchLabels:
      app: web-app
  template:
    metadata:
      labels:
        app: web-app
    spec:
      containers:
      - name: web
        image: nginx:alpine
        ports:
        - containerPort: 80
        resources:
          requests:
            cpu: 100m
            memory: 128Mi
          limits:
            cpu: 200m
            memory: 256Mi
---
apiVersion: v1
kind: Service
metadata:
  name: web-app
  namespace: autoscale-demo
spec:
  selector:
    app: web-app
  ports:
  - port: 80
    targetPort: 80
  type: ClusterIP

View Solution

Solution

1. Install Metrics Server

# Install metrics server (if not already installed)
kubectl apply -f https://github.com/kubernetes-sigs/metrics-server/releases/latest/download/components.yaml

# For local clusters (Minikube, Kind), you may need to disable TLS verification
kubectl patch deployment metrics-server \
  -n kube-system \
  --type='json' \
  -p='[{"op": "add", "path": "/spec/template/spec/containers/0/args/-", "value": "--kubelet-insecure-tls"}]'

# Verify metrics server is running
kubectl get deployment metrics-server -n kube-system

# Wait for metrics to be available
kubectl top nodes
kubectl top pods -A

2. Configure HPA - CPU Based

# hpa-cpu.yaml
apiVersion: autoscaling/v2
kind: HorizontalPodAutoscaler
metadata:
  name: web-app-hpa
  namespace: autoscale-demo
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: web-app
  minReplicas: 2
  maxReplicas: 10
  metrics:
  - type: Resource
    resource:
      name: cpu
      target:
        type: Utilization
        averageUtilization: 50  # Target 50% CPU
  behavior:
    scaleDown:
      stabilizationWindowSeconds: 300  # Wait 5 min before scaling down
      policies:
      - type: Percent
        value: 50  # Scale down max 50% of pods at a time
        periodSeconds: 60
    scaleUp:
      stabilizationWindowSeconds: 0  # Scale up immediately
      policies:
      - type: Percent
        value: 100  # Double pods if needed
        periodSeconds: 60
      - type: Pods
        value: 4  # Or add max 4 pods at a time
        periodSeconds: 60
      selectPolicy: Max  # Use policy that scales fastest

3. Configure HPA - Memory Based

# hpa-memory.yaml
apiVersion: autoscaling/v2
kind: HorizontalPodAutoscaler
metadata:
  name: web-app-memory-hpa
  namespace: autoscale-demo
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: web-app
  minReplicas: 2
  maxReplicas: 10
  metrics:
  - type: Resource
    resource:
      name: memory
      target:
        type: Utilization
        averageUtilization: 70  # Target 70% memory

4. Configure HPA - Multi-Metric

# hpa-multi.yaml
apiVersion: autoscaling/v2
kind: HorizontalPodAutoscaler
metadata:
  name: web-app-multi-hpa
  namespace: autoscale-demo
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: web-app
  minReplicas: 2
  maxReplicas: 10
  metrics:
  # CPU metric
  - type: Resource
    resource:
      name: cpu
      target:
        type: Utilization
        averageUtilization: 50
  # Memory metric
  - type: Resource
    resource:
      name: memory
      target:
        type: Utilization
        averageUtilization: 70
  # Pods metric (requests per second per pod)
  - type: Pods
    pods:
      metric:
        name: http_requests_per_second
      target:
        type: AverageValue
        averageValue: "1000"
  behavior:
    scaleDown:
      stabilizationWindowSeconds: 300
      policies:
      - type: Pods
        value: 1
        periodSeconds: 60
    scaleUp:
      stabilizationWindowSeconds: 0
      policies:
      - type: Percent
        value: 50
        periodSeconds: 30

5. Application with Custom Metrics

// app-with-metrics.js
const express = require('express');
const promClient = require('prom-client');

const app = express();
const port = 3000;

// Prometheus metrics
const register = new promClient.Registry();
promClient.collectDefaultMetrics({ register });

const httpRequestsTotal = new promClient.Counter({
  name: 'http_requests_total',
  help: 'Total HTTP requests',
  labelNames: ['method', 'path', 'status']
});

const httpRequestDuration = new promClient.Histogram({
  name: 'http_request_duration_seconds',
  help: 'HTTP request duration',
  labelNames: ['method', 'path']
});

register.registerMetric(httpRequestsTotal);
register.registerMetric(httpRequestDuration);

// Middleware to track metrics
app.use((req, res, next) => {
  const start = Date.now();

  res.on('finish', () => {
    const duration = (Date.now() - start) / 1000;
    httpRequestDuration.labels(req.method, req.path).observe(duration);
    httpRequestsTotal.labels(req.method, req.path, res.statusCode).inc();
  });

  next();
});

// Routes
app.get('/', (req, res) => {
  res.send('Hello World!');
});

// CPU-intensive endpoint
app.get('/cpu', (req, res) => {
  const iterations = 1000000;
  let result = 0;
  for (let i = 0; i < iterations; i++) {
    result += Math.sqrt(i);
  }
  res.json({ result });
});

// Metrics endpoint
app.get('/metrics', async (req, res) => {
  res.set('Content-Type', register.contentType);
  res.end(await register.metrics());
});

app.listen(port, () => {
  console.log(`App listening on port ${port}`);
});

6. Load Testing

# load-generator.yaml
apiVersion: v1
kind: Pod
metadata:
  name: load-generator
  namespace: autoscale-demo
spec:
  containers:
  - name: load
    image: busybox
    command:
    - /bin/sh
    - -c
    - |
      while true; do
        wget -q -O- http://web-app.autoscale-demo.svc.cluster.local
        sleep 0.01
      done

# Or use Apache Bench
kubectl run -it --rm load-generator \
  --image=httpd:alpine \
  --restart=Never \
  --namespace=autoscale-demo \
  -- ab -n 100000 -c 100 http://web-app.autoscale-demo.svc.cluster.local/

Explanation

How HPA Works

1. Metrics Collection

Metrics Server → API Server → HPA Controller
                                    ↓
                          Calculates desired replicas
                                    ↓
                            Updates Deployment

2. Scaling Algorithm

desiredReplicas = ceil[currentReplicas * (currentMetricValue / desiredMetricValue)]

Example:

  • Current: 2 replicas, 80% CPU usage
  • Target: 50% CPU
  • Desired: ceil[2 * (80 / 50)] = ceil[3.2] = 4 replicas

3. Scaling Behavior

Scale Up:

  • Immediate (or custom stabilization window)
  • Can add multiple pods at once
  • Aggressive to handle load spikes

Scale Down:

  • Delayed (default 5 minutes)
  • Gradual (prevents flapping)
  • Conservative to maintain stability

Key Concepts

Resource Requests

Critical for HPA:

resources:
  requests:
    cpu: 100m      # HPA uses this as 100%
    memory: 128Mi

HPA calculates percentage based on requests, not limits.

Scaling Policies

behavior:
  scaleUp:
    policies:
    - type: Percent    # Scale by percentage
      value: 100
    - type: Pods       # Or by pod count
      value: 4
    selectPolicy: Max  # Use fastest scaling

Cooldown Periods

stabilizationWindowSeconds: 300  # Wait 5 min before scaling

Prevents rapid scaling (flapping).

Try to solve the challenge yourself first!

Click "Reveal Solution" when you're ready to see the answer.

Result

Deploy and Test

# Deploy application
kubectl apply -f app.yaml

# Deploy HPA
kubectl apply -f hpa-cpu.yaml

# Verify HPA
kubectl get hpa -n autoscale-demo

# Output:
# NAME          REFERENCE            TARGETS   MINPODS   MAXPODS   REPLICAS
# web-app-hpa   Deployment/web-app   0%/50%    2         10        2

# Watch HPA in real-time
kubectl get hpa -n autoscale-demo --watch

Generate Load

# Deploy load generator
kubectl apply -f load-generator.yaml

# Watch scaling happen
kubectl get hpa -n autoscale-demo --watch

# After load starts:
# NAME          REFERENCE            TARGETS    MINPODS   MAXPODS   REPLICAS
# web-app-hpa   Deployment/web-app   85%/50%    2         10        2
# web-app-hpa   Deployment/web-app   85%/50%    2         10        4
# web-app-hpa   Deployment/web-app   65%/50%    2         10        4
# web-app-hpa   Deployment/web-app   48%/50%    2         10        4

# Watch pods scaling
kubectl get pods -n autoscale-demo --watch

# Check deployment replicas
kubectl get deployment web-app -n autoscale-demo

Monitor Scaling Events

# View HPA events
kubectl describe hpa web-app-hpa -n autoscale-demo

# Events:
# Type    Reason             Age   Message
# ----    ------             ----  -------
# Normal  SuccessfulRescale  2m    New size: 4; reason: cpu resource utilization above target

# View HPA details
kubectl get hpa web-app-hpa -n autoscale-demo -o yaml

# Check metrics
kubectl top pods -n autoscale-demo

Stop Load and Watch Scale Down

# Delete load generator
kubectl delete pod load-generator -n autoscale-demo

# Watch scale down (takes ~5 minutes)
kubectl get hpa -n autoscale-demo --watch

# After 5+ minutes:
# NAME          REFERENCE            TARGETS   MINPODS   MAXPODS   REPLICAS
# web-app-hpa   Deployment/web-app   48%/50%   2         10        4
# web-app-hpa   Deployment/web-app   12%/50%   2         10        4
# web-app-hpa   Deployment/web-app   5%/50%    2         10        3
# web-app-hpa   Deployment/web-app   3%/50%    2         10        2

Validation

Testing Checklist

# 1. Metrics server running
kubectl get deployment metrics-server -n kube-system
# Should be available

# 2. Metrics available
kubectl top nodes
kubectl top pods -n autoscale-demo
# Should show CPU/memory usage

# 3. HPA active
kubectl get hpa -n autoscale-demo
# Should show current/target metrics

# 4. Resource requests set
kubectl get deployment web-app -n autoscale-demo -o yaml | grep -A 4 "resources:"
# Should show requests defined

# 5. Scaling works
# Generate load, verify replicas increase
kubectl get deployment web-app -n autoscale-demo -o jsonpath='{.spec.replicas}'
# Should be > minReplicas when under load

# 6. Scale down works
# Remove load, wait 5+ minutes
# Replicas should return to minReplicas

Advanced Configuration

Custom Metrics with Prometheus

apiVersion: autoscaling/v2
kind: HorizontalPodAutoscaler
metadata:
  name: custom-metrics-hpa
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: web-app
  minReplicas: 2
  maxReplicas: 10
  metrics:
  - type: Pods
    pods:
      metric:
        name: http_requests_per_second
      target:
        type: AverageValue
        averageValue: "1000"

External Metrics

apiVersion: autoscaling/v2
kind: HorizontalPodAutoscaler
metadata:
  name: external-metrics-hpa
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: web-app
  minReplicas: 2
  maxReplicas: 10
  metrics:
  - type: External
    external:
      metric:
        name: queue_depth
        selector:
          matchLabels:
            queue: "orders"
      target:
        type: AverageValue
        averageValue: "30"

Vertical Pod Autoscaler

apiVersion: autoscaling.k8s.io/v1
kind: VerticalPodAutoscaler
metadata:
  name: web-app-vpa
spec:
  targetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: web-app
  updatePolicy:
    updateMode: "Auto"  # Or "Off" for recommendations only

Best Practices

✅ Do's

  1. Set resource requests: Required for HPA
  2. Use stabilization windows: Prevent flapping
  3. Monitor scaling events: Understand behavior
  4. Test scaling: Verify it works
  5. Set appropriate min/max: Based on capacity
  6. Use multiple metrics: More accurate scaling

❌ Don'ts

  1. Don't forget requests: HPA needs them
  2. Don't scale too quickly: Causes instability
  3. Don't use tiny targets: CPU spikes are normal
  4. Don't ignore costs: More pods = more money
  5. Don't skip testing: Validate before production

Share Your Success

Configured autoscaling? Share your results!

Tag @thedevopsdaily on X with:

  • Min/max replica counts
  • Scaling metrics used
  • Load test results
  • Time to scale up/down

Use hashtags: #AdventOfDevOps #Kubernetes #Autoscaling #Day16

Ready to complete this challenge?

Mark this challenge as complete once you've finished the task. We'll track your progress!

Completed this challenge? Share it.

Tag @thedevopsdaily and share it with the community.

Share on XShare on LinkedIn
Proudly Sponsored By

We earn commissions when you shop through the links below.

Bitrise

Bitrise

Managed runners for GitHub Actions

Bitrise Build Hub runs your GitHub Actions jobs on M4 Macs and AMD Linux machines. Change runs-on and keep your workflows, secrets and logs on GitHub.

Learn more
Atomsized

Atomsized

AWS platform engineering and GitOps

Design and automation for reliable AWS and Kubernetes platforms, safer delivery workflows, and preview and UAT environments your engineers can understand and own.

Learn more
DigitalOcean

DigitalOcean

Cloud infrastructure for developers

Simple, reliable cloud computing designed for developers

Learn more
DevDojo

DevDojo

Developer community & tools

Join a community of developers sharing knowledge and tools

Learn more
SMTPfast

SMTPfast

Developer-first email API

Send transactional and marketing email through a clean REST API. Detailed logs, webhooks, and embeddable signup forms in one dashboard.

Learn more
QuizAPI

QuizAPI

Developer-first quiz platform

Build, generate, and embed quizzes with a powerful REST API. AI-powered question generation and live multiplayer.

Learn more

Want to support DevOps Daily and reach thousands of developers?

Become a Sponsor

Found an issue?
