How to Add SSH Keys to GCP Instances Using Terraform
Adding SSH keys to Google Cloud Platform instances with Terraform allows secure access to your VMs. GCP provides two ways to manage SSH keys: project-wide metadata that applies to all instances, and instance-specific metadata for individual VMs. Understanding both approaches helps you implement the right access control for your infrastructure.
This guide covers how to add SSH keys using Terraform for both project-level and instance-level access.
TLDR: Add SSH keys to GCP instances using the metadata argument in google_compute_instance with the key ssh-keys containing username and public key pairs in the format username:ssh-rsa AAAA... [email protected]. For project-wide keys, use google_compute_project_metadata_item with the same format. Use file() to load keys from files, and set enable-oslogin=FALSE in metadata if OS Login is preventing SSH key access.
Basic SSH Key Configuration
Add an SSH key to a single GCP instance:
resource "google_compute_instance" "vm" {
name = "my-vm"
machine_type = "e2-medium"
zone = "us-central1-a"
boot_disk {
initialize_params {
image = "debian-cloud/debian-11"
}
}
network_interface {
network = "default"
access_config {
// Ephemeral public IP
}
}
metadata = {
ssh-keys = "developer:ssh-rsa AAAAB3NzaC1yc2EAAAADAQABAAABgQC... [email protected]"
}
}
The SSH key format is: username:public-key-type public-key-data user@host
Loading SSH Keys From Files
Instead of hard-coding keys, load them from files:
resource "google_compute_instance" "vm" {
name = "my-vm"
machine_type = "e2-medium"
zone = "us-central1-a"
boot_disk {
initialize_params {
image = "debian-cloud/debian-11"
}
}
network_interface {
network = "default"
access_config {}
}
metadata = {
ssh-keys = "developer:${file("~/.ssh/id_rsa.pub")}"
}
}
The file() function reads the public key from your local file system.
Adding Multiple SSH Keys
To add multiple users or multiple keys for the same user, join them with newlines:
resource "google_compute_instance" "vm" {
name = "my-vm"
machine_type = "e2-medium"
zone = "us-central1-a"
boot_disk {
initialize_params {
image = "debian-cloud/debian-11"
}
}
network_interface {
network = "default"
access_config {}
}
metadata = {
ssh-keys = <<-EOT
developer:${file("~/.ssh/developer_id_rsa.pub")}
devops:${file("~/.ssh/devops_id_rsa.pub")}
admin:${file("~/.ssh/admin_id_rsa.pub")}
EOT
}
}
Each line represents one SSH key entry.
Using Variables for SSH Keys
Store SSH keys in variables for better reusability:
variable "ssh_keys" {
type = map(string)
default = {
developer = "ssh-rsa AAAAB3NzaC1yc2EAAAADAQABAAABgQC... [email protected]"
devops = "ssh-rsa AAAAB3NzaC1yc2EAAAADAQABAAABgQC... [email protected]"
}
}
resource "google_compute_instance" "vm" {
name = "my-vm"
machine_type = "e2-medium"
zone = "us-central1-a"
boot_disk {
initialize_params {
image = "debian-cloud/debian-11"
}
}
network_interface {
network = "default"
access_config {}
}
metadata = {
ssh-keys = join("\n", [
for username, pubkey in var.ssh_keys :
"${username}:${pubkey}"
])
}
}
This allows you to manage SSH keys centrally and apply them consistently across instances.
Project-Wide SSH Keys
To add SSH keys that apply to all instances in a project, use google_compute_project_metadata_item:
resource "google_compute_project_metadata_item" "ssh_keys" {
key = "ssh-keys"
value = <<-EOT
developer:${file("~/.ssh/developer_id_rsa.pub")}
devops:${file("~/.ssh/devops_id_rsa.pub")}
EOT
}
resource "google_compute_instance" "vm1" {
name = "vm-1"
machine_type = "e2-medium"
zone = "us-central1-a"
boot_disk {
initialize_params {
image = "debian-cloud/debian-11"
}
}
network_interface {
network = "default"
access_config {}
}
// Project-wide keys automatically apply
}
resource "google_compute_instance" "vm2" {
name = "vm-2"
machine_type = "e2-medium"
zone = "us-central1-a"
boot_disk {
initialize_params {
image = "debian-cloud/debian-11"
}
}
network_interface {
network = "default"
access_config {}
}
// Project-wide keys automatically apply here too
}
Both instances will have access using the project-wide SSH keys.
Blocking Project-Wide SSH Keys
If you want an instance to only use instance-specific keys and ignore project-wide keys:
resource "google_compute_instance" "secure_vm" {
name = "secure-vm"
machine_type = "e2-medium"
zone = "us-central1-a"
boot_disk {
initialize_params {
image = "debian-cloud/debian-11"
}
}
network_interface {
network = "default"
access_config {}
}
metadata = {
block-project-ssh-keys = "true"
ssh-keys = "admin:${file("~/.ssh/admin_id_rsa.pub")}"
}
}
The block-project-ssh-keys = "true" prevents project-wide keys from being applied to this instance.
Handling OS Login
GCP's OS Login feature can interfere with SSH key metadata. If OS Login is enabled, metadata SSH keys won't work unless you disable it for the instance:
resource "google_compute_instance" "vm" {
name = "my-vm"
machine_type = "e2-medium"
zone = "us-central1-a"
boot_disk {
initialize_params {
image = "debian-cloud/debian-11"
}
}
network_interface {
network = "default"
access_config {}
}
metadata = {
enable-oslogin = "FALSE" # Disable OS Login to use SSH key metadata
ssh-keys = "developer:${file("~/.ssh/id_rsa.pub")}"
}
}
If OS Login is enabled organization-wide, this setting at the instance level will override it.
Using OS Login Instead of SSH Keys
Alternatively, use OS Login and manage access through IAM:
resource "google_compute_instance" "vm" {
name = "my-vm"
machine_type = "e2-medium"
zone = "us-central1-a"
boot_disk {
initialize_params {
image = "debian-cloud/debian-11"
}
}
network_interface {
network = "default"
access_config {}
}
metadata = {
enable-oslogin = "TRUE"
}
}
# Grant SSH access via IAM
resource "google_project_iam_member" "ssh_access" {
project = var.project_id
role = "roles/compute.osLogin"
member = "user:[email protected]"
}
# Or for sudo access
resource "google_project_iam_member" "ssh_admin_access" {
project = var.project_id
role = "roles/compute.osAdminLogin"
member = "user:[email protected]"
}
With OS Login, users authenticate using their Google Cloud identity instead of SSH keys in metadata.
Dynamic SSH Key Management
Generate and manage SSH keys dynamically:
resource "tls_private_key" "ssh" {
algorithm = "RSA"
rsa_bits = 4096
}
resource "google_compute_instance" "vm" {
name = "my-vm"
machine_type = "e2-medium"
zone = "us-central1-a"
boot_disk {
initialize_params {
image = "debian-cloud/debian-11"
}
}
network_interface {
network = "default"
access_config {}
}
metadata = {
ssh-keys = "developer:${tls_private_key.ssh.public_key_openssh}"
}
}
# Save private key to local file
resource "local_file" "private_key" {
content = tls_private_key.ssh.private_key_pem
filename = "${path.module}/ssh-key.pem"
file_permission = "0600"
}
output "ssh_command" {
value = "ssh -i ${local_file.private_key.filename} developer@${google_compute_instance.vm.network_interface[0].access_config[0].nat_ip}"
}
This generates a new SSH key pair and configures the instance automatically.
SSH Keys With Instance Templates
For managed instance groups, add SSH keys to the instance template:
resource "google_compute_instance_template" "default" {
name = "app-template"
machine_type = "e2-medium"
disk {
source_image = "debian-cloud/debian-11"
auto_delete = true
boot = true
}
network_interface {
network = "default"
access_config {}
}
metadata = {
ssh-keys = join("\n", [
for username, pubkey in var.ssh_keys :
"${username}:${pubkey}"
])
}
}
resource "google_compute_instance_group_manager" "default" {
name = "app-igm"
zone = "us-central1-a"
version {
instance_template = google_compute_instance_template.default.id
}
base_instance_name = "app"
target_size = 3
}
All instances created from the template will have the same SSH keys.
Service Account SSH Access
If using service accounts for SSH access:
resource "google_service_account" "vm_sa" {
account_id = "vm-service-account"
display_name = "VM Service Account"
}
resource "google_compute_instance" "vm" {
name = "my-vm"
machine_type = "e2-medium"
zone = "us-central1-a"
boot_disk {
initialize_params {
image = "debian-cloud/debian-11"
}
}
network_interface {
network = "default"
access_config {}
}
service_account {
email = google_service_account.vm_sa.email
scopes = ["cloud-platform"]
}
metadata = {
enable-oslogin = "TRUE"
}
}
# Grant service account SSH access
resource "google_project_iam_member" "sa_ssh" {
project = var.project_id
role = "roles/compute.osLogin"
member = "serviceAccount:${google_service_account.vm_sa.email}"
}
Debugging SSH Key Issues
If SSH keys aren't working, check:
1. Verify metadata was applied:
gcloud compute instances describe my-vm --zone=us-central1-a --format="get(metadata.items)"
2. Check OS Login status:
gcloud compute instances describe my-vm --zone=us-central1-a --format="get(metadata.items.enable-oslogin)"
3. Test SSH connection:
ssh -i ~/.ssh/id_rsa developer@<instance-external-ip>
4. Check SSH logs on the instance:
gcloud compute ssh my-vm --zone=us-central1-a --command="sudo tail -f /var/log/auth.log"
Security Best Practices
Use unique keys per user:
variable "team_ssh_keys" {
type = map(string)
default = {
alice = "ssh-rsa AAAAB3... [email protected]"
bob = "ssh-rsa AAAAB3... [email protected]"
carol = "ssh-rsa AAAAB3... [email protected]"
}
}
Never commit private keys to version control:
# .gitignore
*.pem
*_rsa
*.key
ssh-key*
Use strong key types:
# Generate a strong ED25519 key
ssh-keygen -t ed25519 -C "[email protected]"
Rotate keys regularly:
# Use lifecycle to update SSH keys
resource "google_compute_instance" "vm" {
# ... config ...
lifecycle {
create_before_destroy = true
}
}
Complete Example
Here's a complete example with best practices:
variable "project_id" {
type = string
}
variable "ssh_users" {
type = map(string)
default = {
developer = "~/.ssh/developer_ed25519.pub"
devops = "~/.ssh/devops_ed25519.pub"
}
}
locals {
ssh_keys = join("\n", [
for username, keyfile in var.ssh_users :
"${username}:${file(keyfile)}"
])
}
resource "google_compute_instance" "app" {
name = "app-server"
machine_type = "e2-medium"
zone = "us-central1-a"
boot_disk {
initialize_params {
image = "debian-cloud/debian-11"
size = 20
}
}
network_interface {
network = "default"
access_config {
// Ephemeral public IP
}
}
metadata = {
enable-oslogin = "FALSE"
block-project-ssh-keys = "true"
ssh-keys = local.ssh_keys
}
tags = ["ssh-enabled"]
}
# Firewall rule for SSH
resource "google_compute_firewall" "ssh" {
name = "allow-ssh"
network = "default"
allow {
protocol = "tcp"
ports = ["22"]
}
source_ranges = ["0.0.0.0/0"] # Restrict this in production
target_tags = ["ssh-enabled"]
}
output "instance_ip" {
value = google_compute_instance.app.network_interface[0].access_config[0].nat_ip
}
output "ssh_command" {
value = "ssh developer@${google_compute_instance.app.network_interface[0].access_config[0].nat_ip}"
}
Adding SSH keys to GCP instances with Terraform is straightforward using the metadata argument. Choose between instance-specific keys for granular control or project-wide keys for ease of management. Make sure to handle OS Login settings appropriately and follow security best practices for key management.
