Ingress vs Load Balancer in Kubernetes: When to Use Each

Ingress vs Load Balancer in Kubernetes: When to Use Each

When exposing applications in Kubernetes, you have multiple options for routing external traffic to your services. Two commonly confused concepts are Ingress and LoadBalancer services. While both handle external traffic, they serve different purposes and operate at different layers of the networking stack. Understanding when to use each approach will help you design more efficient and cost-effective Kubernetes architectures.

Prerequisites

You'll need a running Kubernetes cluster with kubectl configured. Basic knowledge of Kubernetes services and networking concepts will help you understand the examples in this guide.

Understanding LoadBalancer Services

A LoadBalancer service is a Kubernetes service type that provisions an external load balancer from your cloud provider. This creates a direct path from the internet to your application:

apiVersion: v1
kind: Service
metadata:
  name: web-app-loadbalancer
spec:
  type: LoadBalancer
  selector:
    app: web-app
  ports:
    - port: 80
      targetPort: 8080
      protocol: TCP

When you create this service, your cloud provider automatically provisions a load balancer with a public IP address. This load balancer forwards traffic directly to your pods through the service.

Understanding Ingress

Ingress is a Kubernetes resource that manages external HTTP and HTTPS access to services within your cluster. Unlike LoadBalancer services, Ingress operates at the application layer (Layer 7) and requires an Ingress Controller to function:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: web-app-ingress
spec:
  rules:
    - host: myapp.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: web-app-service
                port:
                  number: 80

This Ingress resource defines routing rules but doesn't create infrastructure by itself. You need an Ingress Controller like NGINX, Traefik, or cloud-specific controllers to implement these rules.

Key Differences Explained

The fundamental difference lies in their scope and capabilities. LoadBalancer services work at the network layer (Layer 4), handling raw TCP/UDP traffic. They provide a 1:1 mapping between external load balancers and services:

# Each LoadBalancer service gets its own external IP
apiVersion: v1
kind: Service
metadata:
  name: frontend-lb
spec:
  type: LoadBalancer
  selector:
    app: frontend
  ports:
    - port: 80
      targetPort: 3000

---
apiVersion: v1
kind: Service
metadata:
  name: api-lb
spec:
  type: LoadBalancer
  selector:
    app: api
  ports:
    - port: 80
      targetPort: 8080

In contrast, Ingress operates at the application layer (Layer 7) and can route multiple services through a single entry point based on hostnames, paths, and other HTTP attributes:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: multi-service-ingress
spec:
  rules:
    - host: frontend.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: frontend-service
                port:
                  number: 80
    - host: api.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: api-service
                port:
                  number: 8080

Cost and Resource Implications

LoadBalancer services can become expensive quickly because each service provisions a separate cloud load balancer. If you have ten services that need external access, you'll pay for ten load balancers:

# This creates multiple expensive cloud load balancers
kubectl apply -f service1-loadbalancer.yaml
kubectl apply -f service2-loadbalancer.yaml
kubectl apply -f service3-loadbalancer.yaml
# ... and so on

Ingress typically uses a single load balancer (for the Ingress Controller) and routes traffic to multiple services based on rules. This approach significantly reduces costs when exposing multiple applications:

# One Ingress can handle multiple services
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: cost-effective-ingress
spec:
  rules:
    - host: shop.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: shop-frontend
                port:
                  number: 80
          - path: /api
            pathType: Prefix
            backend:
              service:
                name: shop-api
                port:
                  number: 8080
    - host: blog.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: blog-service
                port:
                  number: 80

Advanced Features and Capabilities

Ingress controllers offer sophisticated routing capabilities that LoadBalancer services cannot provide. You can implement SSL termination, URL rewriting, and request routing based on headers or other HTTP attributes:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: advanced-ingress
  annotations:
    nginx.ingress.kubernetes.io/rewrite-target: /$2
    nginx.ingress.kubernetes.io/ssl-redirect: 'true'
    cert-manager.io/cluster-issuer: 'letsencrypt-prod'
spec:
  tls:
    - hosts:
        - api.example.com
      secretName: api-tls-secret
  rules:
    - host: api.example.com
      http:
        paths:
          - path: /v1(/|$)(.*)
            pathType: Prefix
            backend:
              service:
                name: api-v1
                port:
                  number: 8080
          - path: /v2(/|$)(.*)
            pathType: Prefix
            backend:
              service:
                name: api-v2
                port:
                  number: 8080

LoadBalancer services handle traffic more simply but cannot perform application-layer operations like SSL termination or path-based routing.

When to Use LoadBalancer Services

LoadBalancer services work best for specific scenarios where you need direct, low-level network access. Use LoadBalancer services when:

  • You need to expose non-HTTP protocols (like databases, message queues, or custom TCP/UDP applications)
  • You require the highest possible performance with minimal latency
  • You're running a single service that needs external access
  • You need to preserve client IP addresses without additional configuration

Here's an example of exposing a PostgreSQL database:

apiVersion: v1
kind: Service
metadata:
  name: postgres-external
spec:
  type: LoadBalancer
  selector:
    app: postgres
  ports:
    - port: 5432
      targetPort: 5432
      protocol: TCP

When to Use Ingress

Ingress excels at managing HTTP/HTTPS traffic for web applications and APIs. Choose Ingress when:

  • You're exposing multiple HTTP/HTTPS services
  • You need advanced routing based on hostnames, paths, or headers
  • You want to terminate SSL at the edge
  • You need to implement rate limiting, authentication, or other middleware
  • Cost optimization is important (multiple services through one load balancer)

This example shows a typical web application setup:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: web-app-ingress
  annotations:
    nginx.ingress.kubernetes.io/rate-limit: '100'
    nginx.ingress.kubernetes.io/auth-type: basic
    nginx.ingress.kubernetes.io/auth-secret: basic-auth
spec:
  tls:
    - hosts:
        - myapp.example.com
      secretName: myapp-tls
  rules:
    - host: myapp.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: frontend
                port:
                  number: 80
          - path: /api
            pathType: Prefix
            backend:
              service:
                name: backend-api
                port:
                  number: 8080
          - path: /admin
            pathType: Prefix
            backend:
              service:
                name: admin-panel
                port:
                  number: 3000

Hybrid Approaches

You can combine both approaches in the same cluster. Use LoadBalancer services for specific needs and Ingress for general web traffic:

# LoadBalancer for database access
apiVersion: v1
kind: Service
metadata:
  name: redis-external
spec:
  type: LoadBalancer
  selector:
    app: redis
  ports:
    - port: 6379
      targetPort: 6379

---
# Ingress for web applications
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: web-services
spec:
  rules:
    - host: www.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: web-frontend
                port:
                  number: 80

Performance Considerations

LoadBalancer services typically offer better performance for high-throughput applications because they operate at the network layer with fewer processing overhead. The traffic path is more direct:

Internet → Cloud Load Balancer → Kubernetes Service → Pod

Ingress introduces additional processing layers, especially when using features like SSL termination or complex routing rules:

Internet → Cloud Load Balancer → Ingress Controller → Kubernetes Service → Pod

However, modern Ingress controllers are highly optimized and the performance difference is often negligible for most applications.

Security and Compliance

Ingress controllers offer more security features out of the box, including SSL termination, authentication, and rate limiting. You can implement Web Application Firewall (WAF) rules directly in the Ingress configuration:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: secure-app
  annotations:
    nginx.ingress.kubernetes.io/whitelist-source-range: '10.0.0.0/8,192.168.0.0/16'
    nginx.ingress.kubernetes.io/limit-rps: '10'
spec:
  rules:
    - host: secure.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: secure-app
                port:
                  number: 80

LoadBalancer services require additional components or cloud provider features to implement similar security measures.

Migration Strategies

If you're currently using multiple LoadBalancer services and want to reduce costs, you can migrate to Ingress gradually. Start by identifying HTTP/HTTPS services that can benefit from Ingress routing:

# First, install an Ingress controller
kubectl apply -f https://raw.githubusercontent.com/kubernetes/ingress-nginx/controller-v1.8.2/deploy/static/provider/cloud/deploy.yaml

# Create Ingress resources for your HTTP services
kubectl apply -f your-ingress-config.yaml

# Test the new routing
curl -H "Host: yourapp.example.com" http://ingress-controller-ip/

# Once verified, remove the old LoadBalancer services
kubectl delete service old-loadbalancer-service

Next Steps

You now understand the key differences between Ingress and LoadBalancer services in Kubernetes. Consider exploring specific Ingress controllers like NGINX, Traefik, or cloud-specific options to find the best fit for your use case. Look into service mesh technologies like Istio for even more advanced traffic management capabilities.

Good luck with your Kubernetes networking setup!
