Communication Between Multiple Docker-Compose Projects

TLDR

To enable communication between multiple Docker-Compose projects, use shared networks by defining external networks in the docker-compose.yml files. This allows containers from different projects to interact seamlessly.

---

When working with Docker Compose, you may need to enable communication between containers in different projects. For example, a microservices architecture might have separate Compose files for the frontend, backend, and database services. This guide will show you how to configure networking to enable communication between multiple Docker-Compose projects.

Step 1: Create a Shared Network

Docker networks allow containers to communicate with each other. To enable communication between multiple Compose projects, create a shared network:

docker network create shared-network

This command creates a Docker network named shared-network.

Step 2: Configure the First Project

In the docker-compose.yml file of the first project, define the shared-network as an external network:

version: '3.8'
services:
  app:
    image: my-app
    networks:
      - shared-network

networks:
  shared-network:
    external: true

Explanation

• The networks section under services specifies that the app service will use the shared-network.
• The networks section at the bottom declares shared-network as an external network.

Step 3: Configure the Second Project

In the docker-compose.yml file of the second project, also define the shared-network as an external network:

version: '3.8'
services:
  db:
    image: postgres
    networks:
      - shared-network

networks:
  shared-network:
    external: true

Explanation

• The db service in the second project is connected to the same shared-network.
• This allows the app service from the first project to communicate with the db service.

Step 4: Start the Projects

Start both projects using Docker Compose:

docker-compose up -d

Run this command in the directories of both projects. The containers will be connected to the shared network.

Step 5: Test Communication

To test communication between the containers, use the container names as hostnames. For example, from the app container, you can connect to the db container:

ping db

This verifies that the app container can reach the db container.

Additional Options

Use Aliases

You can define aliases for services to simplify communication:

networks:
  shared-network:
    external: true
    aliases:
      - database

Environment Variables

Pass environment variables to configure communication settings:

environment:
  DB_HOST: db
  DB_PORT: 5432

DNS Resolution

Docker's internal DNS resolves container names to IP addresses, making it easy to connect services using their names.

Best Practices

• Use External Networks: Always use external networks for inter-project communication.
• Secure Communication: Use firewalls or Docker's network settings to restrict access.
• Monitor Traffic: Use tools like docker network inspect to monitor network configurations.

By following these steps, you can enable seamless communication between multiple Docker-Compose projects, making it easier to manage complex containerized applications.
