Day 8 - Deploy a Small App on Kubernetes

Description

You have a containerized application that runs perfectly with Docker, but you need to deploy it to Kubernetes for better scalability, self-healing, and orchestration. Time to learn the Kubernetes basics.

Task

Deploy a Node.js application to Kubernetes with proper configuration.

Requirements:

• Create Kubernetes Deployment
• Expose application via Service
• Configure environment variables with ConfigMap
• Add health checks (liveness and readiness probes)
• Verify application is running and accessible

Target

• ✅ Application deployed to Kubernetes
• ✅ Service routes traffic to pods
• ✅ Health checks working
• ✅ Application accessible via LoadBalancer or NodePort
• ✅ Multiple replicas running

Sample App

Application Code

app.js

const express = require('express');
const app = express();
const port = process.env.PORT || 3000;
const appName = process.env.APP_NAME || 'MyApp';
const version = process.env.VERSION || '1.0.0';

let healthy = true;
let ready = true;

// Simulate startup time
setTimeout(() => {
  ready = true;
  console.log('Application is ready!');
}, 5000);

app.get('/', (req, res) => {
  res.json({
    app: appName,
    version: version,
    hostname: require('os').hostname(),
    uptime: process.uptime(),
    timestamp: new Date().toISOString()
  });
});

app.get('/health', (req, res) => {
  if (healthy) {
    res.status(200).json({ status: 'healthy' });
  } else {
    res.status(503).json({ status: 'unhealthy' });
  }
});

app.get('/ready', (req, res) => {
  if (ready) {
    res.status(200).json({ status: 'ready' });
  } else {
    res.status(503).json({ status: 'not ready' });
  }
});

// Endpoint to toggle health (for testing)
app.post('/health/toggle', (req, res) => {
  healthy = !healthy;
  res.json({ healthy });
});

app.listen(port, () => {
  console.log(`${appName} v${version} listening on port ${port}`);
});

Dockerfile

FROM node:18-alpine

WORKDIR /app

COPY package*.json ./
RUN npm ci --only=production

COPY . .

EXPOSE 3000

USER node

CMD ["node", "app.js"]

package.json

{
  "name": "k8s-demo-app",
  "version": "1.0.0",
  "main": "app.js",
  "scripts": {
    "start": "node app.js"
  },
  "dependencies": {
    "express": "^4.18.0"
  }
}

Result

Build and Push Image

# Build the Docker image
docker build -t your-registry/demo-app:1.0.0 .

# Push to registry
docker push your-registry/demo-app:1.0.0

# Or use local registry (Minikube)
eval $(minikube docker-env)
docker build -t demo-app:1.0.0 .

Deploy to Kubernetes

# Apply all manifests
kubectl apply -f namespace.yaml
kubectl apply -f configmap.yaml
kubectl apply -f deployment.yaml
kubectl apply -f service.yaml

# Or apply all at once
kubectl apply -f all-in-one.yaml

# Watch rollout
kubectl rollout status deployment/demo-app -n demo-app
# deployment "demo-app" successfully rolled out

Verify Deployment

# Check pods
kubectl get pods -n demo-app
# NAME                        READY   STATUS    RESTARTS   AGE
# demo-app-5d7f8c9b4d-abc12   1/1     Running   0          30s
# demo-app-5d7f8c9b4d-def34   1/1     Running   0          30s
# demo-app-5d7f8c9b4d-ghi56   1/1     Running   0          30s

# Check service
kubectl get svc -n demo-app
# NAME       TYPE           EXTERNAL-IP   PORT(S)        AGE
# demo-app   LoadBalancer   <pending>     80:30123/TCP   1m

# Get service details
kubectl describe svc demo-app -n demo-app

# For Minikube, get URL
minikube service demo-app -n demo-app --url
# http://192.168.49.2:30123

Test Application

# Get the service URL
SERVICE_URL=$(minikube service demo-app -n demo-app --url)

# Test the app
curl $SERVICE_URL
# {
#   "app": "Advent Demo App",
#   "version": "1.0.0",
#   "hostname": "demo-app-5d7f8c9b4d-abc12",
#   "uptime": 42.5,
#   "timestamp": "2025-12-08T12:00:00.000Z"
# }

# Test health endpoint
curl $SERVICE_URL/health
# {"status":"healthy"}

# Test readiness
curl $SERVICE_URL/ready
# {"status":"ready"}

Validation

Health Check Validation

# Check pod health status
kubectl get pods -n demo-app -o wide
# Should show all pods Running and Ready 1/1

# View pod events
kubectl describe pod demo-app-xxx -n demo-app
# Should show successful Liveness and Readiness probes

# Test probe failure
POD=$(kubectl get pod -n demo-app -l app=demo-app -o jsonpath='{.items[0].metadata.name}')
kubectl exec -n demo-app $POD -- curl -X POST localhost:3000/health/toggle

# Watch pod restart
kubectl get pods -n demo-app -w

Load Balancing Test

# Make multiple requests
for i in {1..10}; do
  curl -s $SERVICE_URL | jq -r .hostname
done

# Should show different pod hostnames (load balancing working)

Scaling Test

# Scale up
kubectl scale deployment demo-app -n demo-app --replicas=5

# Watch scaling
kubectl get pods -n demo-app -w

# Scale down
kubectl scale deployment demo-app -n demo-app --replicas=2

Advanced Features

Horizontal Pod Autoscaler

apiVersion: autoscaling/v2
kind: HorizontalPodAutoscaler
metadata:
  name: demo-app
  namespace: demo-app
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: demo-app
  minReplicas: 3
  maxReplicas: 10
  metrics:
  - type: Resource
    resource:
      name: cpu
      target:
        type: Utilization
        averageUtilization: 70

Ingress (for HTTP routing)

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: demo-app
  namespace: demo-app
  annotations:
    kubernetes.io/ingress.class: nginx
spec:
  rules:
  - host: demo.example.com
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: demo-app
            port:
              number: 80

Best Practices

✅ Do's

1. Use namespaces: Organize resources
2. Set resource limits: Prevent resource hogging
3. Add health checks: Enable self-healing
4. Use ConfigMaps: Externalize configuration
5. Label everything: Enable selection and filtering
6. Use rolling updates: Zero-downtime deployments

❌ Don'ts

1. Don't run as root: Security risk
2. Don't use :latest tag: Unpredictable updates
3. Don't skip health checks: Miss failures
4. Don't hardcode config: Use ConfigMaps
5. Don't forget resource limits: Risk cluster stability

Links

• Kubernetes Documentation
• Kubernetes Deployments
• Kubernetes Services
• Configure Liveness/Readiness Probes
• Minikube

Share Your Success

Deployed your first app to Kubernetes? Celebrate!

Tag @thedevopsdaily on X with:

• Screenshot of running pods
• Application URL/response
• Number of replicas
• What you learned

Use hashtags: #AdventOfDevOps #Kubernetes #CloudNative #Day8
