Day 14 - Networking Debugging

Description

Your pods can't communicate with each other. DNS lookups are failing, services aren't reachable, and you suspect network policies might be blocking traffic. Time to dive into Kubernetes networking and debug the issues.

Task

Debug and fix networking issues in a Kubernetes cluster.

Requirements:

• Diagnose DNS resolution problems
• Fix service connectivity issues
• Debug network policies
• Verify pod-to-pod communication
• Test external connectivity

Target

• ✅ DNS resolution working
• ✅ Services accessible from pods
• ✅ Network policies correctly configured
• ✅ Pod-to-pod communication functional
• ✅ External endpoints reachable

Sample App

Broken Networking Setup

broken-app.yaml

apiVersion: v1
kind: Namespace
metadata:
  name: broken-net
---
# Frontend app
apiVersion: apps/v1
kind: Deployment
metadata:
  name: frontend
  namespace: broken-net
spec:
  replicas: 1
  selector:
    matchLabels:
      app: frontend
  template:
    metadata:
      labels:
        app: frontend
        tier: frontend
    spec:
      containers:
      - name: frontend
        image: nginx:alpine
        ports:
        - containerPort: 80
---
# Backend app
apiVersion: apps/v1
kind: Deployment
metadata:
  name: backend
  namespace: broken-net
spec:
  replicas: 1
  selector:
    matchLabels:
      app: backend
  template:
    metadata:
      labels:
        app: backend
        tier: backend
    spec:
      containers:
      - name: backend
        image: hashicorp/http-echo
        args:
        - -text=backend
        - -listen=:5678
        ports:
        - containerPort: 5678
---
# Backend service (wrong selector!)
apiVersion: v1
kind: Service
metadata:
  name: backend
  namespace: broken-net
spec:
  selector:
    app: api  # Wrong! Should be 'backend'
  ports:
  - port: 80
    targetPort: 5678
---
# Network policy that blocks everything
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: deny-all
  namespace: broken-net
spec:
  podSelector: {}
  policyTypes:
  - Ingress
  - Egress

Result

Deploy and Test

# Deploy fixed configuration
kubectl apply -f fixed-app.yaml

# Wait for pods
kubectl wait --for=condition=ready pod -l app=frontend -n fixed-net
kubectl wait --for=condition=ready pod -l app=backend -n fixed-net

# Verify services have endpoints
kubectl get endpoints -n fixed-net

# Output should show:
# NAME       ENDPOINTS
# backend    10.244.1.5:5678,10.244.2.8:5678
# frontend   10.244.1.6:80,10.244.2.9:80

# Test from frontend pod
FRONTEND_POD=$(kubectl get pod -n fixed-net -l app=frontend -o jsonpath='{.items[0].metadata.name}')

kubectl exec -n fixed-net $FRONTEND_POD -- curl -s http://backend
# Should return: backend response

Comprehensive Network Test

# Deploy test pod
kubectl run test -n fixed-net --rm -it --image=nicolaka/netshoot -- /bin/bash

# Inside test pod:

# 1. Test DNS
nslookup backend.fixed-net.svc.cluster.local
# Should resolve

# 2. Test service by name
curl http://backend.fixed-net.svc.cluster.local
# Should work

# 3. Test short name (same namespace)
curl http://backend
# Should work

# 4. Test direct pod IP
POD_IP=$(kubectl get pod -n fixed-net -l app=backend -o jsonpath='{.items[0].status.podIP}')
curl http://$POD_IP:5678
# Might fail due to network policy

# 5. Test external connectivity
curl -I https://google.com
# Should work (unless egress policy blocks)

Validation

Network Debugging Checklist

# 1. Pods are running
kubectl get pods -n fixed-net
# All should be Running

# 2. Services have endpoints
kubectl get endpoints -n fixed-net
# Should show pod IPs

# 3. DNS works
kubectl run dnstest --rm -it --image=busybox -n fixed-net -- nslookup backend
# Should resolve

# 4. Service reachable
kubectl run curltest --rm -it --image=curlimages/curl -n fixed-net -- curl http://backend
# Should return response

# 5. Network policies applied
kubectl get networkpolicy -n fixed-net
# Should show policies

# 6. CoreDNS healthy
kubectl get pods -n kube-system -l k8s-app=kube-dns
# Should be Running

Debugging Commands Reference

# DNS debugging
kubectl run dnsutils --rm -it --image=tutum/dnsutils -- /bin/bash
nslookup <service>
dig <service>

# Network debugging
kubectl run netdebug --rm -it --image=nicolaka/netshoot -- /bin/bash
curl, ping, traceroute, nslookup, dig, nc, tcpdump

# Service endpoints
kubectl get endpoints <service> -n <namespace>

# Network policies
kubectl get networkpolicy -n <namespace>
kubectl describe networkpolicy <name> -n <namespace>

# Pod connectivity
kubectl exec -it <pod> -n <namespace> -- curl http://<service>

# Check network plugin
kubectl get pods -n kube-system | grep -E 'calico|flannel|weave'

Advanced Debugging

Packet Capture

# Capture traffic on pod
kubectl exec -it <pod> -- tcpdump -i any -w /tmp/capture.pcap

# Copy capture file
kubectl cp <pod>:/tmp/capture.pcap ./capture.pcap

# Analyze with Wireshark
wireshark capture.pcap

CNI Plugin Debugging

# Check CNI config
cat /etc/cni/net.d/10-calico.conflist

# Check CNI binaries
ls /opt/cni/bin/

# View CNI logs (depends on plugin)
kubectl logs -n kube-system -l k8s-app=calico-node

Service Mesh Debugging

# If using Istio
istioctl analyze -n <namespace>
kubectl logs -n istio-system -l app=istiod

# Check proxy logs
kubectl logs <pod> -c istio-proxy

Best Practices

✅ Do's

1. Use services: Don't rely on pod IPs
2. Test DNS: Verify resolution first
3. Label consistently: Match selectors to labels
4. Use FQDN: Especially cross-namespace
5. Document policies: Network policies are powerful
6. Monitor CoreDNS: DNS is critical

❌ Don'ts

1. Don't hardcode IPs: Use service names
2. Don't skip health checks: Prevents traffic to broken pods
3. Don't block DNS: Always allow DNS in policies
4. Don't forget namespaces: Include in service names
5. Don't mix ports: Match service to container ports

Links

• Kubernetes Networking
• Network Policies
• DNS for Services
• Debug Services
• Network Policy Recipes
