// advent-of-devops/day-11

Day 11 of 25IntermediateObservability

Basic Observability

Set up monitoring and logging for your Kubernetes application with Prometheus and Grafana.

Updated

Description

Your application is running in Kubernetes, but you have no visibility into its health, performance, or behavior. When something goes wrong, you're flying blind. Time to add observability with metrics, dashboards, and logs.

Task

Set up basic observability for your Kubernetes application.

Requirements:

  • Deploy Prometheus for metrics collection
  • Deploy Grafana for visualization
  • Configure application metrics
  • Create basic dashboards
  • Set up centralized logging

Target

  • ✅ Prometheus collecting metrics
  • ✅ Grafana dashboards showing application health
  • ✅ Application exposing custom metrics
  • ✅ Logs aggregated and searchable
  • ✅ Basic alerts configured

Sample App

Application with Metrics

app-with-metrics.js

const express = require('express');
const promClient = require('prom-client');

const app = express();
const port = process.env.PORT || 3000;

// Create a Registry to register metrics
const register = new promClient.Registry();

// Add default metrics (CPU, memory, etc.)
promClient.collectDefaultMetrics({ register });

// Custom metrics
const httpRequestDuration = new promClient.Histogram({
  name: 'http_request_duration_seconds',
  help: 'Duration of HTTP requests in seconds',
  labelNames: ['method', 'route', 'status_code'],
  buckets: [0.1, 0.5, 1, 2, 5]
});

const httpRequestTotal = new promClient.Counter({
  name: 'http_requests_total',
  help: 'Total number of HTTP requests',
  labelNames: ['method', 'route', 'status_code']
});

const activeConnections = new promClient.Gauge({
  name: 'active_connections',
  help: 'Number of active connections'
});

register.registerMetric(httpRequestDuration);
register.registerMetric(httpRequestTotal);
register.registerMetric(activeConnections);

// Middleware to track requests
app.use((req, res, next) => {
  const start = Date.now();
  activeConnections.inc();

  res.on('finish', () => {
    const duration = (Date.now() - start) / 1000;
    httpRequestDuration.labels(req.method, req.route?.path || req.path, res.statusCode).observe(duration);
    httpRequestTotal.labels(req.method, req.route?.path || req.path, res.statusCode).inc();
    activeConnections.dec();
  });

  next();
});

// Metrics endpoint for Prometheus
app.get('/metrics', async (req, res) => {
  res.set('Content-Type', register.contentType);
  res.end(await register.metrics());
});

// Health check
app.get('/health', (req, res) => {
  res.json({ status: 'healthy' });
});

// Sample endpoints
app.get('/', (req, res) => {
  console.log('INFO: Home page accessed');
  res.json({ message: 'Hello World', timestamp: new Date().toISOString() });
});

app.get('/api/data', (req, res) => {
  console.log('INFO: Data endpoint accessed');
  res.json({ data: [1, 2, 3, 4, 5] });
});

app.get('/api/slow', async (req, res) => {
  console.log('WARN: Slow endpoint accessed');
  await new Promise(resolve => setTimeout(resolve, 2000));
  res.json({ message: 'This was slow' });
});

app.listen(port, () => {
  console.log(`INFO: Server started on port ${port}`);
});

package.json

{
  "name": "observable-app",
  "version": "1.0.0",
  "dependencies": {
    "express": "^4.18.0",
    "prom-client": "^15.0.0"
  }
}

View Solution

Solution

1. Deploy Prometheus Stack

Install with Helm

# Add Prometheus Helm repository
helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
helm repo update

# Install kube-prometheus-stack (Prometheus + Grafana + Alertmanager)
helm install monitoring prometheus-community/kube-prometheus-stack \
  --namespace monitoring \
  --create-namespace \
  --set prometheus.prometheusSpec.serviceMonitorSelectorNilUsesHelmValues=false \
  --set grafana.adminPassword=admin123

2. Configure ServiceMonitor

# servicemonitor.yaml
apiVersion: v1
kind: Service
metadata:
  name: demo-app-metrics
  namespace: demo-app
  labels:
    app: demo-app
spec:
  selector:
    app: demo-app
  ports:
  - name: metrics
    port: 3000
    targetPort: 3000
---
apiVersion: monitoring.coreos.com/v1
kind: ServiceMonitor
metadata:
  name: demo-app
  namespace: monitoring
  labels:
    app: demo-app
    release: monitoring
spec:
  selector:
    matchLabels:
      app: demo-app
  namespaceSelector:
    matchNames:
    - demo-app
  endpoints:
  - port: metrics
    path: /metrics
    interval: 30s

3. Grafana Dashboard

dashboard-configmap.yaml

apiVersion: v1
kind: ConfigMap
metadata:
  name: demo-app-dashboard
  namespace: monitoring
  labels:
    grafana_dashboard: "1"
data:
  demo-app.json: |
    {
      "title": "Demo App Metrics",
      "panels": [
        {
          "title": "HTTP Request Rate",
          "targets": [
            {
              "expr": "rate(http_requests_total{namespace=\"demo-app\"}[5m])",
              "legendFormat": "{{method}} {{route}}"
            }
          ],
          "type": "timeseries"
        },
        {
          "title": "Request Duration (p95)",
          "targets": [
            {
              "expr": "histogram_quantile(0.95, rate(http_request_duration_seconds_bucket{namespace=\"demo-app\"}[5m]))",
              "legendFormat": "{{route}}"
            }
          ],
          "type": "timeseries"
        },
        {
          "title": "Active Connections",
          "targets": [
            {
              "expr": "active_connections{namespace=\"demo-app\"}",
              "legendFormat": "{{pod}}"
            }
          ],
          "type": "timeseries"
        },
        {
          "title": "Error Rate",
          "targets": [
            {
              "expr": "rate(http_requests_total{namespace=\"demo-app\",status_code=~\"5..\"}[5m])",
              "legendFormat": "5xx errors"
            }
          ],
          "type": "timeseries"
        }
      ]
    }

4. Logging with Loki and Grafana Alloy

The old loki-stack chart is deprecated, and Promtail reached end of life on March 2, 2026. Today's setup uses the current Loki chart in monolithic mode (one pod, good for a lab) and Grafana Alloy to collect the logs. The Loki chart is now published in the grafana-community Helm repository; Alloy stays in the grafana repository.

Install Loki

# loki-values.yaml
deploymentMode: Monolithic
loki:
  auth_enabled: false          # single tenant, no X-Scope-OrgID header needed
  commonConfig:
    replication_factor: 1      # required for a single replica
  storage:
    type: filesystem           # chunks and index on the pod's volume; use object storage in production
  schemaConfig:
    configs:
      - from: "2024-04-01"
        store: tsdb
        object_store: filesystem
        schema: v13
        index:
          prefix: loki_index_
          period: 24h
singleBinary:
  replicas: 1
# The chart defaults to 3 replicas of the scalable targets; monolithic mode needs 0
backend:
  replicas: 0
read:
  replicas: 0
write:
  replicas: 0
# Skip the memcached caches (the chunks cache asks for 8 GB of memory by default)
chunksCache:
  enabled: false
resultsCache:
  enabled: false
lokiCanary:
  enabled: false
test:
  enabled: false

# Add the Grafana community Helm repository (home of the Loki chart)
helm repo add grafana-community https://grafana-community.github.io/helm-charts
helm repo update

helm install loki grafana-community/loki \
  --version 18.17.1 \
  --namespace monitoring \
  --values loki-values.yaml

kubectl wait --for=condition=ready pod/loki-0 -n monitoring --timeout=300s

The chart creates a loki-gateway service on port 80. Alloy pushes logs to it, and Grafana queries it.

Collect logs with Grafana Alloy

Alloy reads container logs through the Kubernetes API, so it needs no host mounts. One replica can collect logs for the whole cluster; running it as a DaemonSet with this config would send every line once per node.

# alloy-values.yaml
controller:
  type: deployment
  replicas: 1
alloy:
  configMap:
    content: |
      // Find every pod in the cluster.
      discovery.kubernetes "pods" {
        role = "pod"
      }

      // Keep namespace, pod and container as Loki labels.
      discovery.relabel "pods" {
        targets = discovery.kubernetes.pods.targets

        rule {
          source_labels = ["__meta_kubernetes_namespace"]
          target_label  = "namespace"
        }
        rule {
          source_labels = ["__meta_kubernetes_pod_name"]
          target_label  = "pod"
        }
        rule {
          source_labels = ["__meta_kubernetes_pod_container_name"]
          target_label  = "container"
        }
      }

      // Tail container logs through the Kubernetes API.
      loki.source.kubernetes "pods" {
        targets    = discovery.relabel.pods.output
        forward_to = [loki.write.default.receiver]
      }

      loki.write "default" {
        endpoint {
          url = "http://loki-gateway.monitoring.svc.cluster.local/loki/api/v1/push"
        }
      }

# Add the Grafana Helm repository (home of the Alloy chart)
helm repo add grafana https://grafana.github.io/helm-charts
helm repo update

helm install alloy grafana/alloy \
  --version 1.13.1 \
  --namespace monitoring \
  --values alloy-values.yaml

The chart's default RBAC already lets Alloy list pods and read pods/log.

Add Loki to Grafana

The Grafana that comes with kube-prometheus-stack loads any ConfigMap labelled grafana_datasource: "1" in its namespace:

# loki-datasource.yaml
apiVersion: v1
kind: ConfigMap
metadata:
  name: loki-datasource
  namespace: monitoring
  labels:
    grafana_datasource: "1"
data:
  loki-datasource.yaml: |
    apiVersion: 1
    datasources:
      - name: Loki
        type: loki
        access: proxy
        url: http://loki-gateway.monitoring.svc.cluster.local

kubectl apply -f loki-datasource.yaml

5. PrometheusRule for Alerts

# prometheusrule.yaml
apiVersion: monitoring.coreos.com/v1
kind: PrometheusRule
metadata:
  name: demo-app-alerts
  namespace: monitoring
  labels:
    release: monitoring
spec:
  groups:
  - name: demo-app
    interval: 30s
    rules:
    - alert: HighErrorRate
      expr: |
        rate(http_requests_total{namespace="demo-app",status_code=~"5.."}[5m]) > 0.05
      for: 5m
      labels:
        severity: warning
      annotations:
        summary: "High error rate detected"
        description: "Error rate is {{ $value }} errors/sec"

    - alert: HighResponseTime
      expr: |
        histogram_quantile(0.95, rate(http_request_duration_seconds_bucket{namespace="demo-app"}[5m])) > 2
      for: 5m
      labels:
        severity: warning
      annotations:
        summary: "High response time"
        description: "P95 response time is {{ $value }}s"

    - alert: PodDown
      expr: |
        up{namespace="demo-app"} == 0
      for: 2m
      labels:
        severity: critical
      annotations:
        summary: "Pod is down"
        description: "Pod {{ $labels.pod }} is down"

Explanation

The Three Pillars of Observability

1. Metrics (Prometheus)

What: Numerical measurements over time

Types:

  • Counter: Only increases (e.g., total requests)
  • Gauge: Can go up or down (e.g., active connections)
  • Histogram: Distributions (e.g., response times)
  • Summary: Similar to histogram, client-side quantiles

Example:

const counter = new promClient.Counter({
  name: 'http_requests_total',
  help: 'Total HTTP requests',
  labelNames: ['method', 'status_code']
});

counter.labels('GET', '200').inc();

2. Logs (Loki)

What: Event records with timestamps

How it flows here: Alloy tails each container's log through the Kubernetes API, adds the namespace, pod and container labels, and pushes the lines to Loki. Loki indexes only those labels, not the text, so a query picks streams by label first and then filters the lines:

# All lines from the demo app
{namespace="demo-app"}

# Only warnings
{namespace="demo-app"} |= "WARN"

# Lines per second, per pod
sum by (pod) (rate({namespace="demo-app"}[5m]))

Keep labels few and bounded. A label such as a user ID creates a new stream for every value.

Best practices:

// Structured logging
console.log(JSON.stringify({
  level: 'INFO',
  message: 'User logged in',
  userId: 123,
  timestamp: new Date().toISOString()
}));

3. Traces (Optional - Jaeger/Tempo)

What: Request flow through distributed system

Not covered today, but next step for advanced observability.

Prometheus Query Examples

# Request rate by status code
rate(http_requests_total[5m])

# Error rate percentage
rate(http_requests_total{status_code=~"5.."}[5m]) /
rate(http_requests_total[5m]) * 100

# P95 latency
histogram_quantile(0.95,
  rate(http_request_duration_seconds_bucket[5m])
)

# CPU usage
rate(container_cpu_usage_seconds_total{pod=~"demo-app.*"}[5m])

# Memory usage
container_memory_working_set_bytes{pod=~"demo-app.*"}

Try to solve the challenge yourself first!

Click "Reveal Solution" when you're ready to see the answer.

Result

Deploy Everything

# Deploy the monitoring stack
helm install monitoring prometheus-community/kube-prometheus-stack \
  --namespace monitoring \
  --create-namespace \
  --set prometheus.prometheusSpec.serviceMonitorSelectorNilUsesHelmValues=false

# Deploy your application
kubectl apply -f deployment.yaml -n demo-app

# Deploy ServiceMonitor
kubectl apply -f servicemonitor.yaml

# Deploy alerts
kubectl apply -f prometheusrule.yaml

# Wait for everything to be ready
kubectl wait --for=condition=ready pod -l app.kubernetes.io/name=prometheus -n monitoring --timeout=300s

Access Dashboards

# Port forward Grafana
kubectl port-forward -n monitoring svc/monitoring-grafana 3000:80

# Default credentials:
# Username: admin
# Password: prom-operator (or what you set)

# Port forward Prometheus
kubectl port-forward -n monitoring svc/monitoring-kube-prometheus-prometheus 9090:9090

# Access:
# Grafana: http://localhost:3000
# Prometheus: http://localhost:9090

View Metrics

# Check if metrics are being collected
curl http://localhost:3000/api/data

# View raw metrics
kubectl port-forward -n demo-app svc/demo-app 3000:3000
curl http://localhost:3000/metrics

# Output:
# # HELP http_requests_total Total number of HTTP requests
# # TYPE http_requests_total counter
# http_requests_total{method="GET",route="/",status_code="200"} 42
# http_requests_total{method="GET",route="/api/data",status_code="200"} 15

Validation

Monitoring Checklist

# 1. Prometheus is scraping targets
kubectl port-forward -n monitoring svc/monitoring-kube-prometheus-prometheus 9090:9090
# Visit http://localhost:9090/targets
# demo-app should show as "UP"

# 2. Metrics are available
# In Prometheus, query: http_requests_total
# Should show data

# 3. Grafana can query Prometheus
kubectl port-forward -n monitoring svc/monitoring-grafana 3000:80
# Visit http://localhost:3000
# Go to Explore, select Prometheus datasource
# Query: http_requests_total

# 4. Dashboards are working
# In Grafana: Dashboards > Browse
# Should see imported dashboards

# 5. Logs are collected
kubectl get pods -n monitoring -l app.kubernetes.io/name=alloy
kubectl get pods -n monitoring -l app.kubernetes.io/name=loki
# In Grafana: Explore > Loki
# Query: {namespace="demo-app"}

# 6. Alerts are configured
# In Prometheus: Alerts
# Should see configured rules

Generate Test Traffic

# Generate load to see metrics
for i in {1..100}; do
  curl http://localhost:3000/
  curl http://localhost:3000/api/data
  curl http://localhost:3000/api/slow
  sleep 0.1
done

# Watch metrics update in Grafana

Advanced Configuration

Custom Grafana Dashboard JSON

{
  "dashboard": {
    "title": "Application Performance",
    "rows": [
      {
        "panels": [
          {
            "title": "Request Rate",
            "targets": [
              {
                "expr": "sum(rate(http_requests_total[5m])) by (route)"
              }
            ]
          }
        ]
      }
    ]
  }
}

AlertManager Configuration

alertmanager:
  config:
    global:
      resolve_timeout: 5m
    route:
      group_by: ['alertname', 'cluster']
      group_wait: 10s
      group_interval: 10s
      repeat_interval: 12h
      receiver: 'slack'
    receivers:
    - name: 'slack'
      slack_configs:
      - api_url: 'YOUR_SLACK_WEBHOOK'
        channel: '#alerts'
        title: 'Alert: {{ .GroupLabels.alertname }}'
        text: '{{ range .Alerts }}{{ .Annotations.description }}{{ end }}'

Best Practices

✅ Do's

  1. Monitor what matters: Focus on user-facing metrics
  2. Use labels wisely: Don't create high cardinality
  3. Set SLOs: Define service level objectives
  4. Create runbooks: Document alert responses
  5. Use dashboards: Visualize key metrics
  6. Structure logs: Use JSON for parsing

❌ Don'ts

  1. Don't ignore scrape errors: Check Prometheus targets
  2. Don't over-alert: Too many alerts = alert fatigue
  3. Don't use unbounded labels: Causes memory issues
  4. Don't log sensitive data: PII, passwords, tokens
  5. Don't skip health checks: Basic but essential

Share Your Success

Set up observability? Share your dashboards!

Tag @thedevopsdaily on X with:

  • Screenshot of Grafana dashboard
  • Metrics you're tracking
  • Most useful query
  • What insights you gained

Use hashtags: #AdventOfDevOps #Prometheus #Grafana #Observability #Day11

Ready to complete this challenge?

Mark this challenge as complete once you've finished the task. We'll track your progress!

Completed this challenge? Share it.

Tag @thedevopsdaily and share it with the community.

Share on XShare on LinkedIn
Proudly Sponsored By

We earn commissions when you shop through the links below.

Bitrise

Bitrise

Managed runners for GitHub Actions

Bitrise Build Hub runs your GitHub Actions jobs on M4 Macs and AMD Linux machines. Change runs-on and keep your workflows, secrets and logs on GitHub.

Learn more
Atomsized

Atomsized

AWS platform engineering and GitOps

Design and automation for reliable AWS and Kubernetes platforms, safer delivery workflows, and preview and UAT environments your engineers can understand and own.

Learn more
DigitalOcean

DigitalOcean

Cloud infrastructure for developers

Simple, reliable cloud computing designed for developers

Learn more
DevDojo

DevDojo

Developer community & tools

Join a community of developers sharing knowledge and tools

Learn more
SMTPfast

SMTPfast

Developer-first email API

Send transactional and marketing email through a clean REST API. Detailed logs, webhooks, and embeddable signup forms in one dashboard.

Learn more
QuizAPI

QuizAPI

Developer-first quiz platform

Build, generate, and embed quizzes with a powerful REST API. AI-powered question generation and live multiplayer.

Learn more

Want to support DevOps Daily and reach thousands of developers?

Become a Sponsor

Found an issue?
